10” multimedia IP video touch screen, Due Fili Plus video door entry indoor station and By-me web-server based system supervisor, complete with mounting frame for installation on box V71318. Cover plate not supplied
EIKON
60,5
Multimedia video touch screen 10” cover plates
21665.11
aluminium
21665.70
diamond white
21665.76
diamond black
Examples of multimedia video touch screenshots
"Video door entry unit" screen of the 10" IP Multimedia video touch screen. "Cameras" screen of the 10" IP Multimedia video touch screen.
4.3” Full Flat colour video touch screen
Besides serving as supervisor for the By-me home automation system, the video touch screen is used as an internal unit of the Due Fili Plus range that can be integrated with all components of the video door entry system (entrance panels, call buttons, power supplies, etc.) and is able to control home automation functions simultaneously with those of the video door entry system, namely viewing and speaking with the caller at the door or gate, releasing the electric lock, switching on the stair lights, making intercom calls, baby watching, etc.; when used as a video door entry, the device is configured directly from the video touch screen, following standard Due Fili Plus procedures. THE screen will also allow the supervision of analogue cameras connected to the circuit of the video door entry system.
Monitoring and control functions (screens, icons, etc.) are configured using the EasyTool Professional LT software application, plugging interface 01991 into the dedicated connector on the device.
Technical specifications
• 4.3” horizontal touch screen display;
• flush mounting installation with 8-module back box V71318 or V71718.
Video door entry function
• view call from external unit;
• communicate with external unit or call button;
• activate electric lock release;
• switch on stair lights or other auxiliary function;
• make or receive an intercom call to/f rom other video touch screens, or hands-free video and audio entry phones;
• ambient listening;
• view images received from multiple TV cameras for room monitoring, baby watching, etc.
Automation and burglar alarm functions
• ON/OFF and dimmer control for lights;
• control of rolling shutters and louvres;
• climate control;
• activation of scenarios;
• sound system;
• view technical alarms;
• display power usage by loads and force their status;
• view status of burglar alarm system and keypad for entering PIN codes to enable on/off/partition control functions;
• Energy Guard.
Note. If the device is used as an internal video door entry unit only, it must be connected in any event to a 12 or 29 Vdc supply. If it is to be used in conjunction with the burglar alarm system, back-up power will be required.
Configuration
The touch screen is configured using the EasyTool Professional LT application and programming interface 01991; the functions (groups, scenarios, etc.) to be controlled by the device are selected from the database downloaded by the By-me control unit used for initial configuration of the system. If the system was configured initially with EasyTool Professional, the database will already have been saved by the software and can therefore be imported directly to the video touch screen.
Conformity to Standards
EMC directive,
Standards EN 50428, EN 50486, EN 50428, EN 50491
Technical data
power supply 12-29 Vdc
current draw at 12 Vdc 180 mA
current draw in standby with 12 Vdc supply 115 mA
current draw at 29 Vdc 100 mA
current draw in standby with 29 Vdc supply 55 mA
current draw on Bus 5.5 mA
operating temperature - 5 °C to + 40 °C (indoor use)
Inputs
29 Vdc power supply V+ V-
Bus digital line (Due Fili Plus) 1, 2 (input/output)
TP bus; + -
external temperature sensor (20432, 19432, 14432)
additional power supply (+28 Vdc, 24 Vac) E+
additional power supply (GND, 24 Vac) E-
NO landing button (doorbell function) FP
ground reference for NO landing button M
Outputs
connection to computer PC
Video termination TV
power supply for additional relay/ringtone + 12V
control for additional ringtone/relay CH
4.3” Full Flat colour video touch screen
4,3” Full Flat colour video touch screen for Due Fili Plus video door entry indoor station, for control and command, 1 input for temperature sensor, complete with support for installation in grey, 8-module box. To be completed with Eikon Evo 8-module cover plates (21668..)
EIKON EVO
57,2
grey
white
neutral
* Suitable for matching with white and Next versions of other devices
Icons for video door entry functions
19558 - 19558.D - 3.5” video door entry Due Fili Plus
Flush mounting 3.5" video door entry designed for stand-alone operation within the Due Fili Plus video door entry system, com- municating directly with the entrance panel.
The device is equipped with a housing for control module 01965 allowing connection to the Bus of the By-me home automation system and operation as supervisor.
Item 19558.D is equipped with a device rendering it suitable for
use by hearing aid wearers.
Designed both for wall-mounted installation with an 8-module (4+4) back box V71318 or V71718, and for table/desktop use, mounted to an angled base 19788.
Operation
With Due Fili Plus, it becomes possible to create systems in which the identification of devices and controls is implemented digitally. Depending on the settings, control operations typical of a video door entry system such as making a call, releasing the electric door lock and switching on stair and hall lights, etc., are all coded. The most important advantage offered by Due Fili Plus is that the entire system can be wired using a twisted pair cable — i.e. just 2 non-polarized conductors — carrying data, audio-video signal and the necessary power to the connected devices.
The system also allows internal calls to be made between video door entrys, between audio entry phones and between video and audio entry phones.
Conformity to Standards
EMC directive,
Standards EN 50486 for 19558 and 19558.D, EN 60118-4 for 19558.D
Technical data
power supply on Bus 28 Vdc
current draw on Bus, Due Fili Plus 200 mA
operating temperature - 5 °C to + 40 °C (indoor use)
Inputs
29 Vdc power supply V+ V-
Bus digital line (Due Fili Plus) 1, 2 (input/output)
additional power supply (+28 Vdc, 24 Vac) E+
additional power supply (GND, 24 Vac) E-
NO landing button (doorbell function) FP
ground reference for NO landing button M
Outputs
power supply for additional relay/ringtone + 12V
control for additional ringtone/relay CH
Call screen active
Camera contrast adjustment screen
3.5” video door entry Due Fili Plus
19558 .B Speakerphone monitor for Due Fili Plus system with 3.5 in screen, with built-in mounting frame for installation in 8-module boxes
To be completed with 8-module Arké cover plates
19558.D .B Speakerphone monitor for Due Fili Plus system with 3.5 in screen, facility for hard of hearing function, with built-in mounting frame for installation in 8-module boxes. To be completed with 8-module Arké cover plates
ARKÉ
19558
19558.D
grey
19558.B
19558.D.B
white
36,5
Colour monitor
The LCD monitor has a built-in microphone and speaker, 4 buttons for video door entry or video surveillance functions, 6 buttons for exploring, selecting and setting functions presented by the home automation menus, a warning LED, and a video colour adjustment trimmer. The rear of the device presents two connectors for:
• video door entry module 01963 or CCTV module 01964 in the top compartment;
• Control unit module 01960 in the bottom compartment.
The LCD monitor is designed both for surface mounting with an 8-module (4+4) back box V71318 or V71718, and for table/ desktop use, mounted to an angled base 20788 (Eikon) or 14788 (Plana).
Integration with CCTV system
The device with video door entry module 01964 can be integrated into a CCTV system as follows:
• basic (view-only functionality with module 01964):
- view single camera feed or DVR recording;
- cyclic selection of cameras using the "lock" button;
- facility of using any given PAL analogue video source (cameras, DVRs, IP cameras with PAL BNC output);
• advanced (view and control functionality with module 01963):
- integration with all video door entry monitors by way of Due Fili Plus Bus and video selector 69AM. The video selector, managed by the Due Fili Plus system as if it were an entrance panel (same topology), is installed together with a video concentrator 69MX. The selector 69AM is assigned an ID by way of the "SaveProg" software tool;
- cyclic selection of cameras using the "lock" button;
- utilization of the same Bus as the video door entry system;
- 4 cameras per module, expandable to a maximum 240 cameras in total;
- additional facility of integrating a DVR with BNC analogue output;
- programming of cyclical self-start function on monitors.
Technical specifications
• LCD: 480x 234 dot, RGB Delta, 0.150x0.216 (mm) dot pitch;
• speaker: 16 Ω, 1W, 500 Hz – 20 kHz;
• microphone: 2 KΩ, 3 Vdc, 0.5 mA, 50 Hz – 16 kHz, S/N 58 dB.
Operation
the LCD monitor can operate in five distinct modes, depending on the combinations in which modules 01960, 01963 and 01964 are connected:
• home automation control unit mode (monitor 21550 or 20550 or 14550 + module 01960);
• Due Fili Plus video door entry mode (monitor 21550 or 20550 or 14550 + module 01963);
• CCTV monitor mode (monitor 21550 or 20550 or 14550 +
module 01964);
• home automation control unit and Due Fili Plus video door entry mode (monitor 21550 or 20550 or 14550 + module 01960 + module 01963);
• home automation control unit and CCTV monitor mode (monitor 21550 or 20550 or 14550 + module 01960 + module 01964).
Conformity to Standards
As for modules 01960, 01963 and 01964.
Colour monitor
Color monitor, LCD 3,5”, to complete with control unit module, video door entry or CCTV modules, with built-in 8-module mounting frame for 8-module (4+4) flush mounting box. To complete with 8-module Eikon Evo (21668...) cover plates, 8-module Eikon Classic (20668...) or Round (20698...) cover plates, or 8-module Plana (14668...) cover plates
EIKON EVO
∆ 21550
grey
∆ 21550.B
white
∆ 21550.N
Next
EIKON
∆ 20550
grey
∆ 20550.B
white
∆ 20550.N
Next
11,8
25,5
PLANA
∆ 14550
white
∆ 14550.SL
Silver
11,8
25,5
The drawings of the side views give the overall dimensions and the depth of the recess in mm ∆ Available until stocks last
01963 - Due Fili Plus video door entry module Integrated with a colour monitor 21550, 20550 or 14550, this module can be turned into a flush mounting hands-free video door entry. The video door entry module is essentially an audio- video interface enabling the interaction of voice and images; the device is provided with inputs and outputs that allow connection of the video door entry with other devices in the system (power supply, stair lights, electrical locks, etc.).
Due Fili Plus video door entry products can be used to create systems in which the identification of devices and controls is implemented digitally. Control operations typical of a video door entry system — such as making a call, releasing the electric door lock and switching on stair and hall lights, etc. — are coded according to the particular configuration. The greatest advantage of the two-wire Due Fili Plus system is that the entire installation can be wired with just two non-polarized conductors: a twisted pair carrying data (Bus), audio signal and video signal, and supplying power to the connected devices. The system also allows intercom calls between video door entrys, between video entry and audio entry phones, and between audio entry phones.
Conformity to Standards
EMC directive,
Standards EN 61000-6-1, EN 61000-6-3
NOTE: Conformity to Standards refers to module 01963 when connected to monitor 21550, 20550 or 14550.
Technical data
power supply on Bus 12-29 Vdc
current draw from AUX power supply 250 mA
operating temperature - 5 °C to + 40 °C (indoor use)
Inputs
Bus digital line (Due Fili Plus) 1, 2 (input/output)
additional power supply (+28 Vdc, 24 Vac) E+
additional power supply (GND, 24 Vac) E-
NO landing button (doorbell function) FP
ground reference for NO landing button M
Outputs
Due Fili Plus video door entry module
01963 Elvox Due Fili Plus video door entry module for 21550, 20550 and 14550 monitor
01963
Accessories to complete 3,5” video door entry unit
V71318 8-module (4+4) flush mounting box, GW 650 °C, for masonry walls, light blue
V71718 8-module mounting box (GW 850 °C), for hollow walls, light blue
V71328 Antimortar cover for V71318 and V71718 flush mounting boxes, yellow
V71631 Cover for V71318 and V71718 flush mounting boxes, snap fixing to V71328 antimortar cover (provided), white
19788 .B Table mounting box, 8 (4+4) modules Arké. To complete with Classic or Round cover plates 20788 .B .N Table mounting box, 8 (4+4) modules Eikon. To complete with Classic or Round cover plates 14788 .SL As above, for Plana
ARKÉ
19788
grey
19788.B
white
V71328 V71631 V71718
V71318
EIKON PLANA
20788
grey
20788.B
white
20788.N
Next
14788
white
14788.SL
Silver
Hands-free audio entry phone for Due Fili Plus call system The hands-free audio entry phone, for installation exclusively with digital Due Fili Plus systems, allows communication with the external unit (Due Fili Plus entrance panel or landing call button 20577, 19577, 14577).
The device has three keys on the front, used for hands-free communication, auxiliary and lock release functions, also two trimmers for adjusting speaker and ring tone volume levels, and a button for selecting the ID code of the unit.
Accessible on the back (terminals side) are: Bus line selection jumper, expansion connector for intercom call buttons, connector for programming parameters from a computer, using interface 692I/U and "SaveProg" software tool.
Technical specifications
• speaker: 16 Ω, 1W, 500 Hz – 20 kHz;
• microphone: 2 KΩ, 3 Vdc, 0.5 mA, 50 Hz – 16 kHz, S/N 58 dB.
Operation
• When a call is made from an external unit (entrance panel or landing call button) the entry phone activates the ring tone; to answer and communicate with the caller, button “A” is pressed and then held for the entire duration of the conversation.
• The auxiliary function can be used to operate an external service, such as stair lights or other loads, which are activated by sending the relative digital control signal. The function is activated by pressing button “B".
• The 'open' function allows the user to release the electric lock of the door or gate — wired directly to the entrance panel — by sending the "Lock" control signal. The function is activated by pressing button “C".
• The audio entry phone can be set up to make and receive voice intercom calls. To make intercom calls, one or more buttons with NO contacts (e.g. 20008, 19008, 14008 or 20066, 19066, 14066) must be wired using the connection cable supplied with the product, and the entry phone configured so that is enabled to make/receive calls to/from other entry phones. A maximum 3 buttons type 20066, 19066 or 14066 can be connected for 6 calls, or 3 buttons type 20008, 19008 or 14008 for 3 calls. There is also the additional or alternative option of programming buttons “B” and “C” to give 2 intercom calls (instead of stair lights and lock release).
• The functionality of buttons “B” and “C” (i.e. the digital control signal sent over the Bus) is programmable from a personal computer using interface 692I/U and the "SaveProg" software tool.
Conformity to Standards
EMC directive,
Standards EN 61000-6-1, EN 61000-6-3
Technical data
power supply on Bus 28 Vdc
current draw during call 150 mA
current draw in stand-by 5 mA
operating temperature - 5 °C to + 40 °C (indoor use)
Inputs
Bus 1 n° 1
Bus 2 n° 2
GND n° 4
additional ringtone n° 6S
doorbell n° 6P
connector for external buttons INTERC
Outputs
Hands-free audio entry phone for Due Fili Plus call system
Speakerphone for Due Fili Plus system with door opening and stair lights switching on functions - 3 modules
EIKON
20557
grey
20557.B
white
20557.N
Next
ARKÉ
19557
grey
19557.B
white
PLANA
white Silver
Due Fili Plus landing call button
The device, for installation exclusively with digital Due Fili Plus systems, allows a visitor to call and communicate with the internal unit (hands-free audio entry phone 20557, 19557, 14557 or monitor 21550, 20550, 14550 complete with Due Fili Plus video door entry module 01963 and with other internal units of the Due Fili Plus series such as the video door entry 19558 or video touch screen 21553.1, 21554).
The device comes complete with a button and illuminated nameplate on the front, whilst the rear affords access to two trimmers for adjusting speaker volume and microphone sensitivity, also to the BUS line selection jumper, the jumper for configuring the type of call, the connector for programming configuration parameters from a computer, and the button for coding the device.
Technical specifications
• speaker: 16 Ω, 1W, 500 Hz – 20 kHz;
• microphone: 2 KΩ, 3 Vdc, 0.5 mA, 50 Hz – 16 kHz, S/N 58 dB.
Operation
The call is made by pressing the button against the name; the user of the internal unit can then choose or decline to enable conversation. For best audio results, the caller should stand and speak at a distance no greater than 40 cm from the device. The Due Fili Plus landing call button can be used to open a door lock by means of an external 12 Vdc relay, connected to terminals ‘+12’ and ‘S’. Speaker volume and microphone sensitivity are adjusted by means of trimmers located on the back of the device.
The landing call button in a video door entry system can be used in conjunction with a video camera 20560, 14560 or 20565,14565 and illuminator 20570, 14570; connection of the
cameras will require the installation of audio-video interface 69AM, which allows the video signal to be sent to the internal video door entry unit when a call is made from the landing.
Conformity to Standards
EMC directive,
Standards EN 61000-6-1, EN 61000-6-3
Technical data
power supply on Bus 28 Vdc
current draw during call 150 mA
current draw in stand-by 5 mA
operating temperature - 5 °C to + 40 °C (indoor use)
Inputs
Bus 1 n° 1
Bus 2 n° 2
lock release n° S
Outputs
PC connection PC
Bus line termination TV
12 Vdc (max 40 mA) + 12V
Due Fili Plus landing call button
Call button for the landing with luminous name-plate, built-in microphone and speaker, for Due Fili Plus - 3 modules
EIKON
20577
grey
20577.B
white
20577.N
Next
grey white
PLANA
14577
white
14577.SL
Silver
732H/100 - Due Fili Plus cable for installation indoors Due Fili Plus cable for installation indoors, twisted pair 2x1 mm2, 100 m (also available in 500 m version, 732H/500).
Conformity to Standards
LV directive,
Standards CEI 20-22/2, EN 60228, EN 60332-1-2
732I/100 - Due Fili Plus cable for installation underground
Due Fili Plus cable for installation underground, twisted pair 2x1 mm2, 100 m (also available in 500 m version, 732I/500).
Conformity to Standards
LV directive, Standards CEI 20-22/3-5, EN 60228, EN 50266-2-4
Due Fili Plus cables
732H/100 /500 Due Fili Plus cable for internal laying, twisted pair 2x1 mm2
732I/100 /500 Due Fili Plus cable for installation underground, twisted pair 2x1 mm2
732H/100 - 100 m
732H/500 - 500 m
732I/100 - 100 m
732I/500 - 500 m
General
The By-me system allows integration with products of the Elvox CCTV range. This means that automation systems can be created, for residential properties and business premises, in which the supervisors are also used to control CCTV functions. Access to the functions is granted on two levels:
• basic mode, used only for viewing live images captured by IP video cameras;
• advanced mode, for controlling the DVR/NVR (viewing live feeds and recordings) and positioning PTZ cameras.
The flush mounting control unit (21509) manages the By-me home automation system with automation and burglar alarm functions; where integration with the video surveillance system is required, supervisors and TV cameras are needed to make up a complete system.
CCTV systems can incorporate the 10" IP multimedia video touch screen (21553.1), the 4.3" video touch screen (21554), the flush mounting video door entry 19558 or a flush mounting monitor 21550/20550/14550 equipped with CCTV module 01964.
This is an important advantage in the case of renovations, or where buildings have already been prepared to accommodate system upgrades or expansions.
By-me Supervisors
The 10" IP multimedia video touch screen (21553.1) is the device with which CCTV functions can be integrated to best advantage.
The "Cameras" application provides the following basic functions:
- view live feed from one single TV camera at a time (analogue, Due Fili Plus or IP);
Connecting with Elvox DVR/NVRs over a LAN network and using "DVR Controller" (compatible with DVR/NVRs: 46840.D04, 46840.D08, 46840.D16, 46840.W04, 46840.W08, 46840.W16,
46640.W04, 46640.W08, 46640.W16, 46640.W32, 46340.F04,
46340.F08, 46340.F16, 46241.F08, 46241.F16) integrated with
the Vimar interface of the 10" multimedia video touch screen, other advanced functions are made available:
- view live feed from cameras (up to 4 simultaneously);
- remote control of PTZ camera (pan-tilt-zoom);
- playback of recordings;
- screenshot capture;
- multiserver;
- configuration of connection parameters from the multimedia video touch screen interface.
The 4,3" colour video touch screen (21554) displays images received from analogue video cameras of the Due Fili Plus system.
With a Web server (01945) installed in the home automation system, the live feed from IP cameras of the CCTV system can be viewed remotely (on a PC, tablet or smartphone).
The computer used to view images from the cameras must have an internet browser installed (Microsoft Internet Explorer 9 or higher, Firefox 6 or higher, Safari 5.1 or higher, Google Chrome 14 or higher); in the case of mobile devices (iOS, Android), these must be running the By-web application, which can be downloaded free from Apple Store and Play Store.
Functions obtainable with By-me supervisors
Item Function
Camera view View and check
Analogue cameras on video door entry Bus IP cameras Analogue and HD-SDI
DVR check (live, playback, PTZ) IP
NVR check (live, playback, PTZ)
21553.1
21554 - - -
19558 + 01965 - - -
21550 or 20550 or 14550 + 01964 - - -
01945 - - -
Basic elements
The system and the applications available can be set up to provide functions concerned with video monitoring for different areas of the home (rooms and garden, baby-watching), and video surveillance of business premises (shop windows, in-store displays of merchandise, etc.).
CCTV functions can be classified as basic and advanced:
- in the case of basic functions, images captured by the camera can be viewed only in real time;
- with advanced functions there is also the facility of recording images and using video analysis as the basis for other actions. Basic functions need only By-me supervisors and cameras, whereas advanced functions require the addition of recording
devices: DVR or NVR, depending on the technology selected.
System architecture
The CCTV system can be created using analogue or IP video cameras. One of the advantages provided by IP cameras is that images can be transferred to an IP network (local or remote) without using specific gateways.
By-me supervisors allow a direct interface with analogue and
IP cameras; the options are summarized in the following table:
By-me Supervisors
Item Camera view
Analogue cameras on video door entry Bus
IP cameras
21553.1
21554 -
19558 + 01965 -
21550 or 20550 or 14550 +
01964 -
01945 -
The power supply to supervisors is determined by their specifications, as is the case with cameras and DVR/NVRs.
Devices and their use
The following devices can be used to create a CCTV installation integrated with the By-me system:
• 10" IP multimedia video touch screen (21553.1) for local supervision and control provided by an advanced and intuitive touch screen graphic interface; or remote control, by way of web server 01945, or personal computer, smartphone and tablet with internet browser, or iPhone and iPod with By-web application.
With the "Cameras" application already installed in the device, the live feeds from analog (with 69AM video selector) or IP cameras can be viewed in sequence.
In addition, the optional software tool "DVR Controller" will allow the management of Elvox DVRs and NVRs (view recordings, search images, position PTZ cameras).
• 4,3" Full Flat colour video touch screen (21554) for the supervision of analogue cameras connected to the Due Fili Plus circuit of the video door entry circuit (allows sequencing of analogue cameras).
"DVR Controller" software page on 10" IP multimedia video touch screen.
• Arké video door entry (19558), like item 21554, allows the supervision of analogue cameras connected to the Due Fili Plus circuit of the video door entry circuit (sequencing of analogue cameras).
• Web server (01945) allows sequencing of IP cameras only on local or remote network with viewing of images on mobile devices (smartphone and tablet) using the By-web application.
• Flush mounting cameras (20560, 14560, 20565, 14565), available in 1 or 2 module versions: can be trained on the area to be watched, with the image displayed on a flush mounting monitor (21550, 20550 and 14550), on video touch screens (21554 and 21553.1) or on the Arké video door entry (19558). The 2 module camera incorporates a microphone for ambient listening. Can be connected to a DVR for recording (video/ video+audio), or to an IP video encoder for live viewing over the data network.
• Indoor and outdoor video cameras (refer to the Elvox CCTV catalogue) for surveillance of areas inside and outside the building; these are available with analogue, IP or HD-SDI technology to meet different installation requirements and allow integration with By-me supervisors, according to their respective capabilities.
• DVR/NVR (refer to the Elvox CCTV catalogue), for recording the video streams of cameras connected to the device, which will analyze the images to detect motion, and interface with By- me supervisors via the IP network. Live viewing with 21553.1 and "DVR Controller" app. control.
• Flush mounting monitor (19558) able to display transmitted images and interface audio functionality for ambient listening.
• Power supplies rated 24 and 12 Vdc (refer to the Elvox catalogue) specified for the respective cameras.
Flush mounting camera 20565.N with illuminator 20570.N
10" IP multimedia video touch screen showing "DVR Controller" page
Example showing integration of CCTV with By-me home automation system.
IP video cameras Bus burglar alarm
Contact interface
(46216.212) (20490.1)
Web server
(01945)
(46226.212)
NVR (46241.F16)
(46216.212)
IP connection
(46226.212)
IP connection
10" IP multimedia video touch screen
(21553.1)
(46216.212) Switch Router
(52SW/24P)
Internet
IP connection
(46216.212)
Analogue video cameras
Bus burglar alarm
Contact
interface Router
(20490.1) Internet
COAX IP connection
(46627.212D)
(46816.212D) COAX Switch IP connection (52SW/24P)
(46627.212D)
COAX
(46816.212D) COAX
10" IP multimedia video touch screen
Analogue DVR (46840.W08) (21553.1)
HD-SDI video cameras
Bus burglar alarm
Contact Router
interface Internet
(20490.1)
IP connection
COAX
(46316.210A) Switch IP connection
(46322.003A) (52SW/24P)
COAX
COAX
(46326.210A) 10" IP multimedia video touch screen
HD-SDI DVR (46340.F04) (21553.1)
Integration with By-me burglar alarm system Interfacing the CCTV system with the By-me burglar alarm system, it becomes possible:
• to record an alert from the CCTV system (a motion event captured by a camera, for example) connected to the By-me system by way of a digital output, generating an alarm specific to the associated zone;
• to activate the camera recording of an event detected by the By-me burglar alarm system;
• to pilot the preprogrammed positioning of a pan-tilt camera trained on the alarm zone (connecting it to the input of the DVR).
Exploiting alarm inputs and outputs provided on DVR/NVR devices and the relative accessories, basic integrations with sensors and alarm functions of the By-me burglar alarm system are made possible:
• following a CCTV alarm alert (e.g. "motion detection", cable
disconnected, etc.), or the closure of a voltage-free contact (01820, 01821, 01822, 01823, 01825, 01826, 01832...,
01737, 01738, 01744) connected to the contact interface
(20490.1, 19490.1, 16940.1, 14490.1), the DVR/NVR
activates a burglar alarm zone and sends a message to mobile devices via the web server;
• the DVR/NVR detects the status of the burglar alarm output following the closure of a voltage-free contact and generates an alarm via the CCTV system, which can:
a. send a snapshot taken via the relative camera (the transmission of an e-mail to a selected address can be programmed);
b.r etrieve the preset position of a pan-tilt camera so that it can be trained on the area of interest (where the alarm was tripped);
c. enable recording of the associated channel.
In the event of an open window being detected, it becomes possible to activate a camera of the CCTV system connected to the DVR, and start recording images.
It may happen, for example, that:
• the contacts interface connected to the By-me burglar alarm Bus detects that a window contact is open;
• the signal passes along the Bus, alarm status is activated and the relay operated actuator pilots the DVR to begin recording the camera feed;
• the DVR records a snapshot taken by the camera and sends it to a selected e-mail address.
There is also the option of creating an "Away" scenario whereby the DVR starts to record when a voltage-free contact is closed; on returning home subsequently, the contact opens and recording is suspended.
Minidome and Dome IP cameras for outdoor use
Models 46222.036 46226.212
Sensor 1/3" CMOS progresive Scan 1/2,9" CMOS progresive Scan
Resolution 1280 x 960 - 1,3 Mpx 1920 x 1080 - 2 Mpx
Sensitivity 0 Lux (IR LED ON) 0 Lux (IR LED ON)
Video compressor H264 H264
Day & night ICR ICR
Lens 3,6 mm 2,8 - 12 mm
Primary frame rate 30 fps (1280 x 960)
30 fps (1280 x 720) 30 fps (1920 x 1080)
30 fps (1280 x 720)
Secondary frame rate 10 fps (1280 x 720)
30 fps (640 x 480)
30 fps (320 x 240) 10 fps (1280 x 720)
30 fps (640 x 480)
30 fps (320 x 240)
Bit Rate 64 Kbs - 4 Mbs 64 Kbs - 8 Mbs
SD card No Yes, not provided
in/out audio 1/0 1/1
In/out alarm No 1/1
CVBS video output No Yes
WDR Yes Yes
Compatibility ONVIF ONVIF
IR 10 - 20 m 20 - 30 m
Protection rating IP66, IK10 IP66, IK10
Operating temperature -10 °C ~ +50 °C -10 °C ~ +50 °C
Power supply/consumption 12 Vdc/PoE 400 mA, 4,8 W 12 Vdc/PoE 500 mA, 6 W
Dimensions (mm) Ø 116 x 91 Ø 150 x 114
Weight (g) 605 880
Notes RTSP RTSP
Outdoor Bullet IP cameras
Models 46212.004 46216.212
Sensor 1/3" CMOS progresive Scan 1/3" CMOS progresive Scan
Resolution 1280 x 960 - 1,3 Mpx 1920 x 1080 - 2 Mpx
Sensitivity 0 Lux (IR LED ON) 0 Lux (IR LED ON)
Video compressor H264 H264
Day & night ICR ICR
Lens 4 mm 2,8 - 12 mm
Primary frame rate 30 fps (1280 x 960)
30 fps (1280 x 720) 30 fps (1920 x 1080)
30 fps (1280 x 720)
Secondary frame rate 10 fps (1280 x 720)
30 fps (640 x 480)
30 fps (320 x 240) 10 fps (1280 x 720)
30 fps (640 x 480)
30 fps (320 x 240)
Bit Rate 64 Kbs - 4 Mbs 64 Kbs - 8 Mbs
SD card No No
in/out audio 1/0 1/0
In/out alarm No No
CVBS video output No Yes
WDR Yes Yes
Compatibility ONVIF ONVIF
IR 20 - 30 m 30 - 50 m
Protection rating IP66 IP66
Operating temperature -10 °C ~ +50 °C -10 °C ~ +50 °C
Power supply/consumption 12 Vdc/PoE 500 mA, 6 W 12 Vdc/PoE 800 mA, 9,6 W
Dimensions (mm) 87 x 87 x 219 109 x 109 x 264
Weight (g) 635 1115
Notes RTSP. Fixing bracket provided RTSP. Fixing bracket provided
Minidome and Dome IP cameras for outdoor use
46222.036 Minidome IP cameras with Day & Night colours, resolution 1.3 Megapixel (1280x960), fixed 3.6 mm lens, mechanical IR filter, dual stream H264, power supply PoE or 12 Vdc, IR 15 m, DWDR and 3DNR functions, RTSP, ONVIF protocol, protection rating IP 66 and IK10. Dimensions Ø116x91 mm. Weight 605 g
46226.212 Dome IP cameras with Day & Night colours, resolution 2 Megapixel (1920x1080), varifocal 2.8-12 mm lens, mechanical IR filter, dual stream H264, power supply PoE or 12 Vdc, SDCARD slot, IR 30 m, DWDR and 3DNR functions, RTSP, ONVIF protocol, protection rating IP 66 and IK10. Dimensions Ø150x114 mm. Weight 880 g
46222.036 46226.212
Outdoor Bullet IP cameras
46212.004 Bullet IP cameras with Day & Night colours, resolution 1.3 Megapixel (1280x960), fixed 4 mm lens, mechanical IR filter, dual stream H264, power supply PoE or 12 Vdc, IR 30 m, DWDR and 3DNR functions, RTSP, ONVIF protocol, protection rating IP 66. Dimensions 87x87x219 mm. Weight 635 g
46216.212 Bullet IP cameras with Day & Night colours, resolution 2 Megapixel (1920x1080), varifocal 2.8-12 mm lens, mechanical IR filter, dual stream H264, power supply PoE or 12 Vdc, SDCARD slot, IR 50 m, DWDR and 3DNR functions, RTSP, ONVIF protocol, protection rating IP 66. Dimensions 109x109x284 mm. Weight 1115 g
46212.004 46216.212
Video compression H264 H264 H264
Mode of operation PENTAPLEX PENTAPLEX PENTAPLEX
Video input 4 Ch 8 Ch 16 Ch
Video output 1 HDMI, 1 VGA, 1 BNC 1 HDMI, 1 VGA, 1 BNC, 1 SPOT 1 HDMI, 1 VGA, 1 BNC, 1 SPOT
In/out audio 2 / 1 4 / 1 4 / 1
Resolution for recording WD1, D1, HD1, CIF WD1, D1, HD1, CIF WD1, D1, HD1, CIF
VGA/HDMI resolution 1920 x 1080 1920 x 1080 1920 x 1080
Hard disk interface 1 SATA da 3 TB max 1 SATA da 3 TB max 1 SATA da 3 TB max
Max frame rate WD1 @ 100 fps WD1 @ 200 fps WD1 @ 400 fps
In/out alarm - / - 8 / 1 16 / 1
Network interface 1 Ethernet 10/100/1000 Mbps 1 Ethernet 10/100/1000 Mbps 1 Ethernet 10/100/1000 Mbps
Hard disk 1 TB professional 1 TB professional 1 TB professional
USB interface 2 2 2
RS485 PTZ control Yes Yes Yes
CVM Yes Yes Yes
QR CODE Yes Yes Yes
Control via smartphone Windows Mobile, Windows Phone7, Android, iPhone, iPad Windows Mobile, Windows Phone7, Android, iPhone, iPad Windows Mobile, Windows Phone7, Android, iPhone, iPad
Video analysis Motion Detection Motion Detection Motion Detection
Privacy filter Yes Yes Yes
Interface Keypad, mouse, remote control Keypad, mouse, remote control Keypad, mouse, remote control
Power supply/consumption 12 V 2 A 12 V 2 A 12 V 2 A
Operating temperature 0°C ÷ 50°C 0°C ÷ 50°C 0°C ÷ 50°C
Dimensions (mm) 255 x 212 x 45 300 x 270 x 58 300 x 270 x 58
Weight (kg) 2 (HDD not provided) 3,5 (HDD not provided) 3,5 (HDD not provided)
PENTAPLEX: DVR/NVR manages simultaneously the recording, real time visualization, recorded images searching, backup (images copy), remote visualization (internet).
DVR HD-SDI
Models 46340.F04 46340.F08 46340.F16
Video compression H264 H264 H264
Mode of operation PENTAPLEX PENTAPLEX PENTAPLEX
Video input 4 CH HDSDI (1080P, 1920x1080p
25 fps/30 fps) SMPTE 292M 8 CH HDSDI (1080P, 1920x1080p
25 fps/30 fps) SMPTE 292M 16 CH HDSDI (1080P, 1920x1080p
25 fps/30 fps) SMPTE 292M
Video output 1 HDMI, 1 VGA, 1 BNC 1 HDMI, 1 VGA, 1 BNC 1 HDMI, 1 VGA, 1 BNC
Audio input/output 4 / 1 8 / 1 16 / 1
Resolution for recording FULL-HD (1920 x 1080) FULL-HD (1920 x 1080) FULL-HD (1920 x 1080)
VGA/HDMI resolution 1920 x 1080P 60 Hz 1920 x 1080P 60 Hz 1920 x 1080P 60 Hz
Max frame rate FULL-HD (1920 x 1080) @ 100 fps FULL-HD (1920 x 1080) @ 200 fps FULL-HD (1920 x 1080) @ 400 fps
In/out alarm 4 / 4 8 / 4 16 / 4
Network interface 1 Ethernet 10/100/1000 Mbps 1 Ethernet 10/100/1000 Mbps 1 Ethernet 10/100/1000 Mbps
Hard disk interface 2 SATA da 3 TB max 4 SATA da 3 TB max 4 SATA da 3 TB max
Hard disk 1 TB professional 1 TB professional 1 TB professional
USB interface 2 2 2
E-SATA interface - 2 2
RS485 PTZ control Yes Yes Yes
CVM Yes Yes Yes
QR CODE No No No
Control via smartphone Windows Mobile, Windows Phone7, Android, iPhone, IPad Windows Mobile, Windows Phone7, Android, iPhone, IPad Windows Mobile, Windows Phone7, Android, iPhone, IPad
Video analysis Motion Detection Motion Detection Motion Detection
Privacy filter 3 for every channel 3 for every channel 3 for every channel
Interface Keypad, mouse, remote control Keypad, mouse, remote control Keypad, mouse, remote control
Power supply/consumption 12 V 5 A 230 Vac 120 W 230 Vac 120 W
Operating temperature 0°C ÷ +50°C 0°C ÷ +50°C 0°C ÷ +50°C
Dimensions (mm) 430 x 388 x 65 465 × 425 × 100 465 × 425 × 100
Weight (kg) 4,2 (HDD not provided) 6,5 (HDD not provided) 6,5 (HDD not provided)
Notes 1 unità rack 2 unità rack 2 unità rack
PENTAPLEX: DVR/NVR manages simultaneously the recording, real time visualization, recorded images searching, backup (images copy), remote visualization (internet).
Analogue DVR
46840.W04 WD1 digital video recorder with 4 inputs and professional 1TB HDD. Pentaplex function. H264 compression, recording in WD1@100fps, PAL, resolution WD1, D1, CIF, audio 2in/1out, RS485 port, USB x2. BNC, VGA, HDMI outputs, up to fullHD. RJ45 10/100/1000Mbps Ethernet interface. Privacy masking, motion detection. Integrated web server, CVM software. Control via smart- phone. Power supply 12 Vdc, 2A included. Dimensions 300x270x58 mm
46840.W08 WD1 digital video recorder with 8 inputs and professional 1TB HDD. Pentaplex function. H264 compression, recording in WD1@200fps, PAL, resolution WD1, D1, CIF, audio 4in/1out, alarms 8/1, RS485 port, USB x2. BNC, VGA, HDMI outputs, up to fullHD. RJ45 10/100/1000Mbps Ethernet interface. Privacy masking, motion detection. Integrated web server, CVM software. Control via smartphone. Power supply 12 Vdc, 2A included. Dimensions 300x270x58 mm
46840.W16 WD1 digital video recorder with 16 inputs and professional 1TB HDD. Pentaplex function. H264 compression, recording in WD1@400fps, PAL, resolution WD1, D1, CIF, audio 4in/1out, alarms 16/1, RS485 port, USB x2. BNC, VGA, HDMI outputs, up to fullHD. RJ45 10/100/1000Mbps Ethernet interface. Privacy masking, motion detection. Integrated web server, CVM software. Control via smartphone. Power supply 12 Vdc, 3A included. Dimensions 300x270x58 mm
46840.W04 46840.W08
46840.W16
DVR HD-SDI
46340.F04 HD-SDI FullHD Real Time digital video recorder with 4 inputs and professional 1TB HDD. Pentaplex function, H.264 compression record- ing in FullHD@100fps, 4in/1out audio, 4in/4out alarms, RS485 port. BNC, VGA, HDMI outputs, up to fullHD. RJ45 10/100/1000Mbps Ethernet interface. Privacy masking, motion detection. 2 max 3TB SATA interfaces. Integrated web server, CMS software. Control via smartphone. Power supply 12 Vdc, 5A, power supply unit included. Dimensions 430x300x55 mm
46340.F08 HD-SDI FullHD Real Time digital video recorder with 8 inputs and professional 1TB HDD. Pentaplex function, H.264 compression record- ing in FullHD@200fps, 8in/1out audio, 8in/4out alarms, RS485 port. BNC, VGA, HDMI outputs, up to fullHD. RJ45 10/100/1000Mbps Ethernet interface. Privacy masking, motion detection. 4 max 3TB SATA interfaces. Integrated web server, CMS software. Control via smartphone. Power supply 100-240 Vac. Dimensions 490x430x100mm
46340.F16 HD-SDI FullHD Real Time digital video recorder with 16 inputs and professional 1TB HDD. Pentaplex function, H.264 compression record- ing in FullHD@400fps, 16in/1out audio, 16in/4out alarms, RS485 port. BNC, VGA, HDMI outputs, up to fullHD. RJ45 10/100/1000Mbps Ethernet interface. Privacy masking, motion detection. 4 max 3TB SATA interfaces. Integrated web server, CMS software. Control via smartphone. Power supply 100-240 Vac. Dimensions 490x430x100mm
46340.F04 46340.F08
46340.F16
Video compression H264
Mode of operation PENTAPLEX
Video input 8 Ch
Video output 1 HDMI, 1 VGA
In/out audio 1 / 1
Resolution for recording Real Time 1080P 8 channels @ 200 fps
VGA/HDMI resolution 1080P (1920 x 1080)
In/out alarm -
Network interface 1 RJ45 - 10/100/1000 Mbps switch included 4-port RJ45 PoE
Hard disk interface 1 SATA (max 3 TB)
Hard disk 1 TB professional
Plug & Play Yes, (switch PoE included)
USB interface 2
RS485 PTZ control Yes
CVM Yes
QR CODE Yes
Control via smartphone Windows Phone7, Android, iPhone
Video analysis Motion detection
Privacy filter Yes
Interface Keypad, mouse, remote control
Power supply/consumption 110/230 Vac
Operating temperature 0°C ÷ +50°C
Dimensions (mm) 252 x 200 x 45
Weight (kg) 3,5 (HDD not provided)
Notes
NVR IP video recorder
46241.F08 8-CH NVR, H264 compression recording in 4ch@FULLHD realtime or 8ch@HD realtime, built-in PoE switch. Remote control and view- ing, 1 TB HDD professional, Plug&Play configuration. ONVIF protocol. Dimensions 430x300x55 mm. Weight 605 g
46241.F08
01964 - CCTV module
When this module is integrated suitably with colour monitor 21550, 20550 or 14550, the screen can serve as a monitoring system for closed circuit television cameras (CCTV). The CCTV module, for practical purposes, is an audio-video interface that enables a user to view the video signal coming from an indoor and/or outdoor video camera and to listen to the audio signal from a microphone if available. The device is provided with 9 terminals for connections to the system (power supply, cameras, audio inputs, etc.).
Operation
The CCTV module allows the creation of a simple and flexible video surveillance and ambient listening system able to meet the various installation requirements typical of residential buildings and properties.
Conformity to Standards
EMC directive,
Standards EN 61000-6-1, EN 61000-6-3
NOTE: Conformity to Standards refers to module 01964, when connected to monitor 21550, 20550 or 14550.
Inputs
channel 1 audio signal A1
channel 2 audio signal A2
channel 1 video signal V1
channel 2 video signal V2
24 Vdc power supply +
power supply (GND) -
audio signal ground (GND) MA
channel 1 video reference ground (GND) M
channel 2 video reference ground (GND) M
Outputs
connection to LCD monitor PIN-STRIP connector
CCTV module
∆ 01964 CCTV module for 21550, 20550, 14550 monitor
∆ 01964
The drawings of the side views give the overall dimensions and the depth of the recess in mm ∆ Available until stocks last
Colour video camera, 1-module
A camera with automatic zoom and tilt adjustment (± 12°), positioned to capture an image of the caller that will be displayed on video touch screens, on flush mounting monitors or on the screen of the Due Fili Plus video door entry.
Technical specifications
• CCD sensor: 1/4” colour;
• scanning system: 525-line interlaced (NTSC); 625-line interlaced (PAL);
• pan/tilt: ± 12°;
• lens type: pinhole 3.7 mm;
• horizontal resolution: 330 lines TV;
• signal-to-noise ratio: 45 dB;
• shutter: electronic diaphragm;
• video output voltage: 1 Vpp composite video, 75 Ω.
Conformity to Standards
EMC directive, Standards EN 61000-6-1, EN 61000-6-3
Technical data
power supply 12 Vdc ± 20%
current draw 50 mA, 0.6 W
operating temperature - 5 °C to + 40 °C (indoor use)
Inputs
video signal (ground) M
video signal V
power supply (positive) +T
power supply (negative) -
Colour video camera, 2-module
A camera with automatic pan, tilt and zoom adjustment, positioned to capture an image of the caller that will be displayed on flush mounting monitors or on the screens of surface mounting control units and video door entrys. Equipped with a power-on indicator LED and a built-in microphone for ambient listening in CCTV applications.
Technical specifications
• CCD sensor: 1/4” colour;
• scanning system: 525-line interlaced (NTSC); 625-line interlaced (PAL);
• pan/tilt: ± 20°;
• lens type: pinhole 3.7 mm;
• pan coverage: 53°;
• horizontal resolution: 330 lines TV;
• signal-to-noise ratio: 45 dB;
• shutter: electronic diaphragm;
• video output voltage: 1 Vpp composite video, 75 Ω;
• microphone: 2 KΩ, 3 Vdc, 0.5 mA, 50 Hz – 16 kHz, S/N 58 dB.
Conformity to Standards
EMC directive, Standards EN 61000-6-1, EN 61000-6-3
Illuminator
Installed in conjunction with cameras 20560, 14560, 20565 and 14565, this device throws light frontally on the caller so that the video image will be displayed with optimum clarity on the monitor.
The illuminator comprises a high efficiency white light LED, reflector and lens.
Technical specifications
• luminous flux: 9 lm;
• LED wattage: 0,35 W;
• illuminance: 20 lux at 40 cm approx.
Conformity to Standards
EMC directive, Standards EN 61000-6-1, EN 61000-6-3, EN 60825-1
Technical data
power supply 12 Vdc ± 20%
current draw 70 mA, 0.8 W
operating temperature - 5 °C to + 40 °C (indoor use)
Inputs
microphone (negative) n° 7
microphone (positive) n° 6
video signal V
video signal (ground) M
power supply (positive) +T
power supply (negative) -
Technical data
power supply 12-24 Vdc ± 20%
current draw 70 mA
operating temperature - 5 °C to + 40 °C (indoor use)
Inputs
Colour video camera, 1-module
Inner color video camera with vertical adjustment
EIKON
grey
white
Next
54
PLANA
white Silver
Colour video camera, 2-module
Inner color video camera with vertical and horizontal adjustment, built-in microphone - 2 modules
EIKON
PLANA
grey
white
white
Next
Silver
Illuminator
Inner light with high-efficiency LED for color video camera, supply voltage 12-24 Vdc (SELV)
EIKON
grey
white
Next
PLANA
white Silver
The drawings of the side views give the overall dimensions and the depth of the recess in mm
Electronic thermostat
Integrated into the By-me home automation system, the elec- tronic thermostat provides temperature control in 2 or 4 pipe systems (heating/air conditioning) and neutral zone (4 pipe sys- tems only), with "boost" function for activating a second source so that the desired level of thermal comfort can be established more quickly. The thermostat has an RGB backlit display and 6 capacitive buttons for controlling the temperature set point, the speed of the fan coil unit and the configuration of the thermostat operating mode; the colour of the display is adjusted from the control unit (21509) or using the EasyTool Professional software application. The thermostat is a universal 2-module device for the Eikon, Arkè and Plana series.
Main functions:
• temperature control algorithms: ON/OFF or PID, selectable via user interface:
- the ON/OFF algorithm is the type of control whereby, when- ever the temperature setting plus a threshold value is exceed- ed (contrariwise for air conditioning), the heating is switched off, and will switch on again when the room temperature falls below the selected setting;
- proportional-integral-derivative control, or PID, is an advanced algorithm able to maintain a more stable room temperature, which operates by switching the system on and off when appropriate in such a way as to determine a gradual rise or fall in heating (or cooling) output from the system; ideal for underfloor systems, the algorithm must be suitably calibrated according to the nature of the surroundings and the characteristics of the system;
• the colour scheme of the RGB display can be:
- fixed, with user-selectable colour;
- coordinated with the backlighting of the residential series; or alternatively, with the "Ecometer" function, it can intuitively reflect the level of power usage by the system compared to the standard value (see note on page alongside);
• the "boost" function allows preferred climate conditions to be established more quickly when using a second source (e.g. fan coil), and only in the event of the difference between measured and set point temperatures being greater than a selectable threshold.
Technical specifications
• RGB backlit touch display with configurable colours;
• display of unit of measure associated with the device;
• display of relative humidity in a room or area;
• option of connecting an external NTC temperature sensor (20432, 19432, 14432 or 02965): maximum length of cable connecting sensor and devices: 60 m. Use a twisted cable with minimum section of 0.5 mm2 (01840);
• device compatible only with control unit 21509 or EasyTool Professional software application (01992);
• installation: flush or surface mounting (with back box 09975…).
Technical data
power supply on By-me Bus 29 Vdc
current draw on By-me Bus 5 mA
control range in heating mode +5 °C to 30 °C
control range in cooling mode +10 °C to 35 °C
operating temperature - 0 °C to + 40 °C (indoor use)
Inputs
TP bus; Bus + -
electronic temperature sensor
Conformity to Standards
LV Directive, EMC Directive, Standards EN 50428, EN 50491
Electronic thermostat
Thermostat for touch screen home automation for ON/OFF, PWM and PID temperature control (heating and air conditioning), 2 and 4 pipe system management, 3 speed and proportional fan-coil control, 1 input for NTC wired or flush mounting temperature sensor, RGB LED backlighting, to be completed with Eikon, Arké or Plana cover plates - 2 modules
grey white
Note
The ECOmeter mode allows the backlighting colour to be set. Depending on the set temperature, it is associ- ated with the estimated energy consumption level; it does not display the colour according to the temperature measured at that moment but solely according to the set-point.
blue teal green yellow red
low consumption optimum consumption excessive consumption
Examples of RGB display colours coordinated with the Eikon, Arké and Plana series.
With Eikon Chrome cover plate and amber backlighting With Arké cover plate and blue backlighting With Plana Silver cover plate and green backlighting
Thermostat
Integrated with the By-me home automation system for the management of temperature control and energy usage, the device is designed to maintain a selected room temperature (heating and air conditioning). Can be subordinated to the control unit in "timer-thermostat" mode or used to manage a selected zone independently in "thermostat" mode.
Technical specifications
• control range:
- with heating in operation, +5 – +30 °C;
- with aircon in operation, +10 – +35 °C;
• device not compatible with proportional actuators (01466);
• installation: flush or surface mounting (with back box 09975…).
Inputs
TP bus Bus + -
Conformity to Standards
EMC directive, Standard EN 50428
Fan coil thermostat
Integrated with the By-me home automation system for the management of temperature control and energy usage, the device is designed to maintain a selected room temperature (heating and air conditioning) in conjunction with a 3-speed fan coil unit.
Technical specifications
• control range:
- with heating in operation, +5 – +30 °C;
- with aircon in operation, +10 – +35 °C;
• device not compatible with proportional actuators (01466);
• temperature differential: adjustable between 0.1 °C and 1.0 °C; default: 0.2 °C The adjustment is made from the control unit.
Technical data
power supply on Bus 29 Vdc
current draw on Bus 20 mA
operating temperature - 5 °C to + 40 °C (indoor use)
Inputs
TP bus Bus + -
Conformity to Standards
EMC directive Standard EN 50428
Thermostat
Thermostat with display, room temperature control - 2 modules
EIKON
ARKÉ
IDEA
PLANA
∆ 20514
grey
∆ 20514.B
white
∆ 19514
grey
16954
grey
∆ 20514.N
Next
∆ 19514.B
white
16954.B
white
36
26,5
36,8
∆ 14514
white
∆ 14514.SL
Silver
Termostato fan coil
Thermostat with display to control fan coil, automatic and manual 3-speed mode - 2 modules
EIKON
ARKÉ
∆ 20513
grey
∆ 20513.B
white
∆ 20513.N
Next
36,7
26,5
IDEA
∆ 19513
grey
16953
grey
∆ 19513.B
white
16953.B
white
36,8
26
PLANA
∆ 14513
white
∆ 14513.SL
Silver
37,2
25,5
Bus temperature probe
Integrated into the By-me home automation system, the device provides temperature control in 2 or 4 pipe systems (heating/air conditioning) and neutral zone (4 pipe systems only), with "boost" function for activating a second source so that the desired level of thermal comfort can be established more quickly.
Main functions:
• temperature control algorithms: ON/OFF or PID, selectable via user interface:
- the ON/OFF algorithm is the type of control whereby, when- ever the temperature setting plus a threshold value is exceed- ed (contrariwise for air conditioning), the heating is switched off, and will switch on again when the room temperature falls below the selected setting;
- proportional-integral-derivative control, or PID, is an advanced algorithm able to maintain a more stable room temperature, which operates by switching the system on and off when appropriate in such a way as to determine a gradual rise or fall in heating (or cooling) output from the system; ideal for underfloor systems, the algorithm must be suitably calibrated according to the nature of the surroundings and the characteristics of the system;
• used with special By-me actuator to pilot the operation of On/Off heating/cooling valves, with actuator 01851.2, and of proportional valves (0-10 V, 4-20 mA) with actuator 01466;
• management of fan coil units (3 speeds/proportional, On/Off valves);
• "boost" function: used to pilot the operation of an auxiliary actuator (On/Off, proportional);
• external sensor functions (20432, 19432, 14432, 02965):
- alternative to internal sensor;
- mediation with internal sensor.
Electronic active humidity sensor
Integrated with the By-me home automation system (by way of interface 01467 with analogue input), a sensor allowing the man- agement of temperature control, having the following functions: maintaining humidity below a selected threshold and prevention of condensation in floor-level cooling systems. The device detects the level of relative humidity in the air and relays the information as an analogue signal, either voltage 0-10 V or current 4-20 mA.
Technical specifications
• double insulated from mains;
• for maximum accuracy of measurement, install the device 1.5 m approx above floor level on an inside wall;
Technical specifications
• facility of remote control (touch screen, web server);
• option of connecting an external NTC temperature sensor (20432, 19432, 14432 or 02965): maximum length of cable connecting sensor and devices: 60 m. Use a twisted cable with minimum section of 0.5 mm2 (01840);
• device compatible only with control unit 21509 or EasyTool Professional software application (01992).
Conformity to Standards
LV directive, EMC Directive, Standard EN 50428, EN 50491
Technical data
power supply on Bus 29 Vdc
current draw on Bus 5 mA
control range in heating mode +5 °C to 30 °C
control range in cooling mode +10 °C to 35 °C
temperature differential adjustable from control unit 21509 0.1 °C and 1 °C
reading accuracy -≤ ±0.5 °C between +15 °C and +30 °C
- ≤ ±0.8°C at extremes
operating temperature - 0 °C to + 40 °C (indoor use)
Inputs
TP bus Bus + -
electronic temperature sensor
Technical data
power supply 12-24 V~ 50 Hz, 12-32 Vdc, SELV
maximum input power draw at input 1 W
humidity range in use without condensation 10-90 RH%
typical accuracy of humidity reading in still air at 20 °C and 50 RH% ± 3 RH%
operating temperature - 5 °C to + 45 °C (indoor use)
range displayable on supervisors 10 to 90 RH%
Inputs Outputs
20433 - Front view and connections
• avoid installation in the corners of rooms, in recesses, behind shelves and curtains, likewise near doors, windows, forced air
flows and heat sources;
• maximum length of cable connecting with the receiver device: 100 m. Use twisted pair cable 2x0.5mm² (01840);
• protection class: IP20.
Configuration
The analogue output signal mode can be selected via the rela- tive jumper on the back of the sensor; the desired output mode is obtained by setting the jumper to 0-10 V or to 4-20 mA.
Terminals:
V+: power supply;
- : power supply and output reference;
RH+: output.
Jumper configuration:
RH+ - V+
Jumper
Conformity to Standards
EMC Directive, Standard EN 60730-2-13
Voltage setting Current setting
0-10 V 4-20 mA
Bus temperature probe
Temperature probe for ON/OFF, PWM and PID temperature control (heating and air conditioning), management of 2 and 4 pipe systems, 3 speed and proportional fan-coil control, 1 input for wired or flush mounting NTC temperature sensor, for By-me home automation
EIKON
50,3
20538
grey
20538.B
white
20538.N
Next
ARKÉ
19538
grey
19538.B
white
50,5
11
PLANA
50,3
11,3
14538
white
14538.SL
Silver
Electronic active humidity sensor
Electronic active humidity sensor, 1 output 0-10 V or 4-20 mA, power supply 12/24 V - 2 modules. Can be integrated with the By-me home automation system via 01467
EIKON
10,8
47,8
20433
grey
20433.B
white
20433.N
Next
ARKÉ
48,7
11,7
19433
grey
19433.B
white
PLANA
14433
white
14433.SL
Silver
12,2
48,2
Electronic temperature sensor
Integrated with the By-me home automation system for the management of temperature control and energy usage, the sensor is used with control unit 21509 and touch screens 21554, 21511, 21512.1, 20511.1, 19511 and 14511.1 to dis-
play the ambient temperature in which products are installed.
Technical specifications
• maximum length of cable connecting sensor and devices:
60 m.
Technical data
resistance 25° 10 KΩ
temperature displayable on supervisors - 10 °C to + 70 °C
02965 - Wired temperature sensor
Device used in conjunction with thermostat 02950 and timer- thermostat 02955 to display the ambient temperature in which products are installed.
Technical specifications
• length of cable: 4 m.
Technical data
resistance 25° 10 KΩ
temperature displayable on supervisors - 10 °C to + 70 °C
Electronic temperature sensor
Electronic temperature sensor, 1 output
20432
grey
20432.B
white
20432.N
Next
ARKÉ
19432
grey
19432.B
white
14432
white
14432.SL
Silver
Wired temperature sensor
02965 Wired temperature sensor, cable length 4 m
KNX weather station
The weather station can be integrated with the By-me home automation system for managing temperature control, energy usage and automated functions. The weather station measures quantities such as temperature, wind speed, rainfall and bright- ness, of which the values can be used for:
- viewing on supervisors;
- activating automated functions in the home automation sys- tem, when threshold values are exceeded.
Main functions:
• Brightness detection: this function can be used to control outside lights, which are switched on at dusk and switched off at dawn.
• Wind measurement: the strength of the wind is measured electronically, ensuring noiseless and reliable operation even in adverse weather conditions with hail, snow and sub-zero temperatures. The weather station is also able to detect whirlwinds and updraughts. The advantage of this function is that awnings can be rolled up automatically when exposed to strong wind or precipitation.
• Rain sensor: the weather station is equipped with a sensor that has a heated surface, so that only raindrops and snow- flakes (and therefore not fog or dew) are identified as pre- cipitation. The sensor will also deactivate automatic watering systems during rainfall. Once it has stopped raining or snow- ing, the sensor dries quickly and the precipitation message is turned off.
• Temperature measurement: the weather station measures the current temperature value.
Technical specifications
• configuration button;
• CONFIGURATION LED;
• protection class: IP44;
• dimensions: 96x77x118 mm (W x H x D);
• weight: 170 g approx.
Configuration
The functions and parameters of the weather station are con- figured using the EasyTool Professional software tool (01992); the manual and technical data sheet can be downloaded from the Software->Product Software section of the Vimar website www.vimar.com.
Technical data
AUX power supply 12-32 V, 12-24 V~ SELV
current draw, 10% ripple 100 mA
group addresses 254 max
possible associations 255 max
communication objects 109
rain sensor heating 1.2 W
temperature measurement range -40 °C to +80 °C
temperature definition 0.1 °C
temperature accuracy 1 °C with -10 °C – +85 °C
1.5 °C with -25 °C – +150 °C
wind measurement range: 0 - 70 m/s
wind definition <10% of measured value
wind accuracy with angle of incidence 45° and mounting on proper support 25% with 0 - 15 m/s
brightness measurement range 0 - 150,000 Lux
brightness definition 1 Lux with 0-120 Lux
2 Lux with 121-1,046 Lux
63 Lux with 1,047-52,363 Lux
423 Lux with 52,364-150,000 Lux
brightness accuracy 35%
operating temperature - -30 °C to + 50 °C (outdoor use)
Inputs
Conformity to Standards
EMC directive,
Standards EN60730-1, EN 50491
KNX weather station
01546 Weather station, KNX standard, power supply 12-32 Vdc or 12-24 Vac. Can be integrated with the By-me home automation system via Suite PRO 01992
01546
By-me IR interface
The device can be integrated with the By-me home automation system for managing temperature control. In effect, the IR inter- face allows the control of air conditioning splitters, by learning and emulating the signals used by the original remote control of the target devices.
Associated with the touch screen thermostat 02951, touch screen supervisors (21554, 21511, 20511.1, 19511, 14511.1,
21512.1, 20512, 19512, 16952 and 14512) or web server 01945, the interface allows control of the splitters directly by the By-me system, either manually or with scenarios and events. The extension lead for the IR control is supplied (length 3 m).
Technical specifications
• connector for 2.5 mm2 socket;
• facility of programming the relative group by way of control unit 21509 or from a computer running the EasyTool Professional application (01992);
• configuration button;
• LED for configuring and indicating IR reception and transmission;
• facility of recording and replicating up to 32 signals generated by an infrared remote control;
• 3m cable with 2.5 mm2 jack and IR transmitter (supplied).
Technical data
power supply on Bus 29 Vdc
current draw on Bus 20 mA
infrared frequency 30 kHz - 60 kHz
operating temperature - 5 °C to + 45 °C (indoor use)
Inputs
TP bus; Bus +, -
Conformity to Standards
EMC directive,
Standards EN 50428, EN 50491
By-me IR interface
Interface for transmission of By-me commands to IR receiver, complete with 3 m cable
EIKON
PLANA
The drawings of the side views give the overall dimensions and the depth of the recess in mm
01465 - Climate control device for heating systems Integrated with the By-me home automation system for the management of temperature control, this device is used to con- trol the temperature of water in the heating flow line. The water temperature can be controlled in response to outdoor ambient temperature or maintained at a constant value. The device has:
• 1 output for mixer valve with 3-point control;
• 1 output for circulation pump;
• 1 output for proportional mixer valve;
• 3 inputs for temperature sensor:
- outdoor temperature;
- flow temperature;
- optional temperature.
Main functions:
• alarm warning indicating failure of connected temperature sensor;
• management of dew point in combination with humidity sen- sor (20433, 19433, 14433): prevents condensation attribut- able to cooling at floor level;
• anti-seizing function protecting circulation pump and mixer valve;
• timer programming;
• maximum floor temperature protection.
Technical specifications
• open/close output piloting the operation of 3-point control mixer solenoid valves;
• On/Off changeover output for circulation pump;
• analogue output (with overload protection) configurable for voltage or current (0-10V/(0)4-20 mA), piloting the operation of proportional solenoid valves;
• 4 output status indicator LEDs;
• LED and configuration button;
• control of 3 sensors: PT100, PT1000 and NTC (20432, 19432, 14432, 02965);
• reading from 2/3 wire configurable temperature sensors;
• device compatible only with control unit 21509 or EasyTool Professional software application (01992);
• installation on DIN rail (60715 TH35), occupying 6 modules.
Controllable loads
OUT 1 resistive loads: 8 A 120-230 V
cos 0.6 motors: 3.5 A 120-230 V
OUT 2 resistive loads: 8 A 120-230 V
cos 0.6 motors: 3.5 A 120-230 V
OUT 3 voltage output: 0-10 V configurable
minimum load pilotable with voltage setting is 1000 Ω
current output: (0) 4-20 mA configurable
maximum load pilotable with current setting is 500 Ω
NO dimmer ballasts
Conformity to Standards
LV Directive, EMC Directive, Standards EN 60730-2-9, EN 50491
Technical data
power supply 120-230 V~, 50/60 Hz
power draw from mains 5 VA
power supply on TP Bus 29 Vdc, SELV
current draw on TP Bus 5 mA
operating temperature - 5 °C to + 45 °C (indoor use)
Inputs
power supply N, L
TP bus; +, -
sensors T1, T2, T3
Outputs
solenoid valve OUT 1
circulation pump OUT 2
proportional solenoid valve OUT 3
Input Un
Y 0 0 +
Climate control device for heating systems
01465 Climate control device for heating systems, power supply 120-230 V~ 50/60 Hz, 3 inputs for PT100, PT1000 and NTC probes, 1 mixer valve control output, 1 output 0-10 V or (0)4-20 mA, 1 8 A 230 V~ change-over relay output, installation on DIN rail (60715 TH35), occupies 6 modules size 17.5 mm
01466 - Actuator with 4 proportional analogue outputs This is a proportional actuator that can be integrated with the By-me home automation system for the purpose of managing temperature control, automation and sound system functions. The device will activate/regulate the opening movement of motorized proportional valves or fan-coil units operated by variable control signals utilizing voltage (e.g. 0-10 V) or current (e.g. 4-20 mA). Up to 4 valves can be controlled. The functions obtainable independently for each output are:
• piloting the operation of motorized proportional valves for temperature control systems, using a current signal with cus- tomizable range
(0-20 mA or 4-20 mA);
• piloting the operation of motorized proportional valves for temperature control systems, using a voltage signal with cus- tomizable range (0-10 V, 1-10V, 0-5 V, 0-1 V, etc.);
• alarm indicating overload of the output by causing the relative LED to blink (voltage control signal only).
Technical specifications
• maximum distance between actuator and valve: 10 m with twisted pair cable;
• protection class IP20;
• device compatible only with control unit 21509 or EasyTool Professional software application (01992);
• installation on DIN rail (60715 TH35), occupying 4 modules.
Controllable loads
OUT 1 With voltage signal, the minimum load pilotable is
1000 Ω
With current signal, the maximum load pilotable is
500 Ω
OUT 2
OUT 3
OUT 4
Conformity to Standards
LV Directive, EMC Directive, Standards EN 50428, EN 50491
Technical data
power supply 120-230 Vac, 50/60 Hz
power draw from mains 5 VA
power supply on TP Bus 29 V
current draw on TP Bus 5 mA
operating temperature - 5 °C to + 45 °C (indoor use)
Inputs
power supply N, L
TP bus +, -
Outputs
solenoid valves OUT 1, OUT 2, OUT 3, OUT 4
Actuator with 4 proportional analogue outputs
01466 Actuator with 4 proportional analogue outputs (0)4-20 mA or 0-10 V with re-scalable maximum output voltage or current, power supply 120-230 V~ 50/60 Hz, By-me home automation, installation on DIN rail (60715 TH35), occupies 4 modules size 17,5 mm
01467 - Device with 3 analogue signal inputs
The device with analogue signal inputs can be integrated with the By-me home automation system for the management of temperature control and energy usage; it has 3 analogue inputs: 1 input for sensor using 0-10 V voltage signal or 0-20 mA current signal, 1 input for wire or flush mounting NTC temperature sensor and 1 input for brightness sensor (01530).
The brightness sensor is able to deliver energy saving benefits as it will control the amount of artificial light produced when there is sufficient natural light to give the desired level.
Main functions:
The following functions are obtainable with the device:
with temperature sensor input:
• send temperature measurement over Bus;
• lock temperature sensor input;
with voltage or current sensor input:
• send measured quantity over Bus;
• switch a load on or off when a previously set level is exceeded;
• lock voltage or current sensor input;
with brightness sensor input:
• maintain constant light output on the basis of a selectable level of brightness in a room (this operating mode is available only if there is also a dimmer in the same functional group);
• block brightness sensor input.
Technical specifications
• input for temperature sensor 20432, 19432, 14432 and 02965;
• input for brightness sensor 01530;
• input for current or voltage sensor;
• device compatible only with control unit 21509 or EasyTool Professional software application (01992);
• maximum length of sensor cables:
- brightness sensor (01530): 100 m;
- electronic temperature sensor, (20432, 19432, 14432):
60 m;
- current/voltage sensor (20433, 19433, 14433) 100 m;
• all sensors must be connected to SELV devices:
• installation on DIN rail (60715 TH35), occupying 2 modules.
Technical data
power supply on TP Bus 29 Vdc
current draw on TP Bus 20 mA
input resistance with voltage signal 66 kΩ
input resistance with current signal 200 Ω
operating temperature - 5 °C to + 45 °C (indoor use)
Inputs
TP bus; +, -
current or voltage sensor 0-10 V or 0-20 mA
temperature sensor NTC
brightness sensor 01530
Conformity to Standards
EMC directive
Standards EN 50428, EN 50491
Device with 3 analogue signal inputs
01467 Device with 3 analogue signal inputs, 1 input 0-10 V or 4-20 mA, 1 input for linear or flush mounting NTC temperature sensor, 1 input for brightness sensor 01530, for By-me home automation, installation on DIN rail (60715 TH35), occupies 2 modules size 17.5 mm
Actuator with 16 A 230 V~ relay output and current sensor The actuator can be integrated with the By-me home auto- mation system for managing temperature control and energy usage.
The device performs the function of actuator, as well as power metering and calculation of power draw; it will also log energy values and allow the indication of an alarm tripped by a fault condition affecting the load.
The device can be used in automation, energy saving and cli- mate control systems.
Main functions:
• measurement of power drawn by the load;
• monostable/bistable relay response;
• activation/deactivation delay and duration;
• load fault alarm with fault detection power threshold;
• management of scenarios;
• archive logging of energy values.
Technical specifications
• loads controllable at 230 V ~ (NO contact):
- resistive loads: 16 A (20,000 cycles)
- incandescent lamps: 8 A (20,000 cycles)
- fluorescent lamps and energy saving lamps: 1 A (20,000 cycles)
- electronic transformers: 4 A (20,000 cycles)
- ferromagnetic transformers: 10 A (20,000 cycles);
- cos 0.6 motors: 3.5 A (100,000 cycles)
• protection class IP20;
• overvoltage category: III;
• measurement category: III.
Technical data
mains power supply 230 V~ dc, 50 Hz
power supply on Bus 29 Vdc
current draw on Bus 5 mA
operating temperature - 5 °C to + 40 °C (indoor use)
Inputs
TP bus; Bus + -
230 V~ 50 Hz L, 1, N
20537 - Front view and connections
A B C
A: Configuration LED B: configuration button C: TP Bus terminals
Conformity to Standards
LV directive,
Standards EN 61010-1, EN 61010-2-030,
EMC directive,
Standards EN 61000-6-1, EN 61000-6-3
Actuator with 16 A 230 V~ relay output and current sensor
Actuator with relay output 16 A 230 V~ 50 Hz with incorporated current sensor - 2 modules
EIKON
20537
grey
20537.B
white
20537.N
Next
ARKÉ
19537
grey
19537.B
white
PLANA
14537
white
14537.SL
Silver
01451 - Energy meter with current sensor
The meter can be integrated with the By-me home automation system for managing temperature control and energy usage. The device measures the power drawn by a load connected to the mains supply; power consumption and energy dissipation data will be displayed on the touch screens (21553, 21554, 21511, etc.) connected to the By-me Bus.
Technical specifications
• measurement of power levels up to 3680 W;
• configuration using By-me control unit or EasyTool Professional application (01992);
• flush mounting installation (behind inserts);
• protection class IP20;
• overvoltage category: III;
• measurement category: III.
Conformity to Standards
LV directive, Standards EN 61010-1, EN 61010-2-030 EMC directive, Standards EN 61000-6-1, EN 61000-6-3
01452 - Pulse counter interface
The counter can be integrated with the By-me home automa- tion system for managing temperature control and energy usage.
The device serves to count the pulses transmitted by a fiscal meter or allocator for gas, hot and cold water and electricity, or anemometer, etc., and place the resulting data on the By-me bus. The pulse is reproduced on the output side for other similar devices.
Main characteristics
• parameters:
- minimum pulse duration;
- conversion parameters;
- setting of measured quantity;
- setting of initial meter value;
• flush mounting installation (behind inserts);
• configuration using control unit 21509 or EasyTool Professional application (01992);
• device compatible only with control unit 21509 or EasyTool Professional software application;
• protection class IP20;
• overvoltage category: III;
• measurement category: III.
Conformity to Standards
EMC directive,
Standards EN 61010-1, EN 61010-2-030, EN 61000-6-1,
EN 61000-6-3
Technical data
mains power supply 120-230 V~, 50/60 Hz
rated current 16 A
power supply on Bus 29 Vdc
current draw on Bus 5 mA
operating temperature - 5 °C to + 40 °C (indoor use)
Inputs
TP bus; Bus + -
120-230 V~ 50/60 Hz 1, L, N
Technical data
power supply on Bus 29 Vdc
current draw on Bus 10 mA
operating temperature - 5 °C to + 40 °C (indoor use)
Inputs
TP bus Bus +, -
IN (pulse input) +, -
Outputs
OUT (pulse reproduction) +, -
Energy meter with current sensor
01451 Energy meter with incorporated current sensor, measurable powers up t 3680 W, flush mounting (retrofit)
Pulse counter interface
01452 Pulse counter interface for measuring data from devices fitted with pulse outputs, such as electricity, water and gas meters, flush mounting (retrofit)
Energy meter with 3 inputs for toroidal current sensor The meter can be integrated with the By-me home automation system for managing temperature control and energy usage. The device measures the power on one or more mains supply lines. Suitable for both single and three phase systems, and will monitor up to 3 power lines independently.
Current flowing in the monitored power line is measured with a current sensor (01457, 01458); the device will log and archive energy values for each of the individual lines.
Technical specifications
• measurement of power levels: 25 W to 100 kW (up to 33 kW for each line);
• measurement of active power on up to 3 lines (L1, L2 and L3);
• inputs for current sensors (01457, 01458);
• configuration using control unit 21509 or EasyTool Professional application (01992);
• protection class: IP20;
• overvoltage category: III;
• measurement category: III;
• installation on DIN rail (60715 TH35): 1 x 17.5 mm module.
Conformity to Standards
LV directive, Standards EN 61010-1, EN 61010-2-030 EMC directive, Standards EN 61000-6-1, EN 61000-6-3
Technical data
power supply on Bus 29 Vdc
current draw on Bus 5 mA
power supply L1-N 120-230 V, 50/60 Hz
power supply L1-L2-L3-N 127-200 V, 50/60 Hz
230-400 V, 50/60 Hz
operating temperature - 5 °C to + 40 °C (indoor use)
Inputs
TP bus Bus +, -
three-phase power supply L1, L2, L3, N
current sensors (01457, 01458) S1, S2, S3
Load control module with 3 inputs for toroidal current sensor
The load control module can be integrated with the By-me home automation system for managing temperature control and energy usage.
The device prevents the switch in the electricity meter from tripping due to overload; suitable for both single-phase and three-phase systems. Current flowing in the monitored power line is measured with a current sensor (01457, 01458); the module will monitor up to 3 power lines independently. THE module is also designed to monitor systems capable of gen- erating energy (e.g. photovoltaic). If the power cable is not readily accessible, the measurement can be made remotely, using the energy 01450 connected to the By-me bus. It saves the energy values logged from each line in an archive.
Technical specifications
• measurement of power levels: 25 W to 100 kW (up to 33 kW for each line);
• measurement of active power on up to 3 local lines and 3 remote lines;
• inputs for current sensors (01457, 01458);
• configuration using By-me control unit 21509 or EasyTool Professional application(01992);
• protection class: IP20;
• overvoltage category: III;
• measurement category: III;
• installation on DIN rail (60715 TH35): 1 x 17.5 mm module.
Conformity to Standards
LV directive, Standards EN 61010-1, EN 61010-2-030 EMC directive, Standards EN 61000-6-1, EN 61000-6-3
Technical data
power supply on Bus 29 Vdc
current draw on Bus 5 mA
power supply L1-N 120-230 V, 50/60 Hz
power supply L1-L2-L3-N 127-200 V, 50/60 Hz
230-400 V, 50/60 Hz
operating temperature - 5 °C to + 40 °C (indoor use)
Inputs
TP bus Bus +, -
three-phase power supply L1, L2, L3, N
current sensors (01457, 01458) S1, S2, S3
Energy meter with 3 inputs for toroidal current sensor
01450 Energy meter, 3 inputs for toroidal current sensor, measurable powers 25 W-100 kW, single phase power supply 120-230 V 50/60 Hz three phase 230/400 V 50/60 Hz, installation on DIN rail (60715 TH35), occuphies 1 x 17.5 mm module. Supplied with toroidal current sensor 01457
Load control module with 3 inputs for toroidal current sensor
01455 Load control module, 3 inputs for toroidal current sensor, measurable powers 25 W-100 kW, single phase power supply 120-230 V 50/60 Hz three phase 230/400 V 50/60 Hz, installation on DIN rail (60715 TH35), occupies 1 x 17.5 mm module. Supplied with toroidal current sensor 01457
Toroidal current sensor
01457 Toroidal current sensor for load control and power measurement, hole diameter 7.5 mm, cable length 40 cm
Actuator with 16 A 120-230 V~ relay output and built-in current sensor
The actuator can be integrated with the By-me home auto- mation system for managing temperature control and energy usage.
The device performs the function of actuator, as well as power metering and calculation of power draw; it will also log energy values and allow the indication of an alarm condition caused by abnormalities in operation such as current leakage and load- related faults.
The device can be used in automation, energy saving and cli- mate control systems.
Technical specifications
• loads controllable at 120 - 230 V ~ (NO contact):
- resistive loads: 16 A (20,000 cycles)
- incandescent lamps: 8 A (20,000 cycles)
- fluorescent lamps and energy saving lamps: 1 A (20,000 cycles)
- electronic transformers: 4 A (20,000 cycles)
- ferromagnetic transformers: 10 A (20,000 cycles)
- cos 0.6 motors: 3.5 A (100,000 cycles)
• configuration using control unit 21509 or EasyTool Professional application (01992);
• protection class IP20;
• overvoltage category: III;
• measurement category: III;
• installation on DIN rail (60715 TH35): 1 x 17.5 mm module.
Conformity to Standards
LV directive, Standards EN 61010-1, EN 61010-2-030, EMC directive, Standards EN 61000-6-1, EN 61000-6-3
Technical data
power supply on Bus 29 Vdc
current draw on Bus 5 mA
power supply L1-N 120-230 V, 50/60 Hz
operating temperature - 5 °C to + 40 °C (indoor use)
Inputs
TP bus; Bus +, -
power supply L, N
current sensor (01459) Sensor
Actuator with 16 A 120-230 V~ relay output and built-in current sensor
01456 Actuator with relay output 16 A 120-230 V~ 50/60 Hz with incorporated current sensor, 1 input channel for toroidal differential current sensor, installation on DIN rail (60715 TH35), occupies 1 x 17.5 mm module. Supplied without toroidal differential current sensor.
Toroidal current sensor, hole diameter 19 mm
01458 Toroidal current sensor for load control and power measurement, hole diameter 19 mm, cable length 40 cm
01458
Toroidal differential current sensor, hole diameter 9 mm
01459 Toroidal differential current sensor for power actuator, hole diameter 9 mm, cable length 40 cm
01459
The drawings of the side views give the overall dimensions and the depth of the recess in mm
Example of By-me home automation system with temperature control in 4 zones.
Area solenoid valves control
Air-conditioning fan
20584.1.B
OUT 4
OUT 3
OUT 2
OUT 1
AREA A
02965
02951.B
01851.2
AREA B
20538.B
AREA C
AUX +, -
02951.B
AREA D
01400
20538.B
Bus KNX
AUX +, -
Circulation pump Low-temperature
01546
01850.2
Circulation pump High-temperature
146
Manifold
Circulation pump High-temperature
Hydraulic manifold
Heater
Note.
The example illustrated includes underfloor heating, hot towel rails in the bathrooms, and a single or multi split air conditioning system. The By-me home automation system manages all functions by way of a touch screen control unit, thermostats, electronic temperature sensors, actuators, IR interfaces and weather station.
Example of By-me home automation system with temperature control in 6 zones.
Area solenoid valves control Area solenoid valves control
OUT 4 OUT 3 OUT 2 OUT 1 OUT 4 OUT 3 OUT 2 OUT 1
AUX +, -
01467
01851.2
Bus KNX
01546
01851.2
AREA A AREA D
01851.2 02951
02951
AREA B AREA E
02951 02951
AREA C AREA F
20538 20538
AUX +, -
21511
01466
01850.2 01850.2
21509
01400
146 146
Secondary circulation pump
Secondary circulation pump
Convey probe
Main circulation pumps
Note.
Chiller
The example illustrated includes a radiant panel heating/air conditioning system with fan-coil mounting for a 4 pipe system. The system uses thermostats and electronic temperature and humidity sensors connected to the By-me Bus, providing temperature control in various rooms. Timing programs and temperature set points for the single zones can be set from the supervision touch screens of the home automation system.
Example of By-me home automation system with multiple zone temperature control in a business premises.
Note.
In the example illustrated, By-me home automation is used to control a heating system serving two zones (office 1 and 2) equipped with 3-speed fan coil units, and a third zone (office 3) equipped with variable speed (0-10V) fan coil units; energy is saved by opening and closing the windows automatically as appropriate (configurable delay).
Example of By-me home automation system with multiple zone temperature control.
OUT 4
OUT 3
OUT 2
OUT 1
Note.
In the example illustrated, a traditional 2-pipe heating system includes radiators, circulation pump, zone valves and a single boiler. With electronic temperature sensors con- nected to the By-me Bus, settings for the climate controlled zones can be entered locally, by way of supervision touch screens installed in the dwelling, or remotely — if the web server 01945 is installed and connected to the internet — from a smartphone, computer or tablet.
Example of single-phase system (up to 33 kW overall) giving control over 4 loads, with display of single loads and diagnostics function (optional) monitoring leakage to earth in the load circuits.
Notes
Up to 16 loads or groups of loads can be controlled utilizing a similar number of relay actuators. Groups of controlled loads must be assigned a priority determining the order of disconnection.
POWER draw can be measured on up to 20 single loads or groups of loads.
Example of single-phase system (up to 33 kW overall) giving control over 4 loads, with measurement (optional) of energy usage by 2 single loads (oven and dishwasher).
Note.
Up to 16 loads or groups of loads can be controlled utilizing a similar number of relay actuators. Groups of controlled loads must be assigned a priority determining the order of disconnection.
POWER draw can be measured on up to 20 single loads or groups of loads.
Example of single-phase system (up to 33 kW overall) giving control over 4 loads, with measurement (optional) of energy usage by 1 single load (oven) and measurement of photovoltaic output (optional). Just one control unit is installed, supervising all devices.
Notes
Up to 16 loads or groups of loads can be controlled utilizing a similar number of relay actuators. Groups of controlled loads must be assigned a priority determining the order of disconnection.
Setting the parameter "self-supply" for a given group, the load will activate when the power input to the grid exceeds the threshold and remains activated until production exceeds overall consumption. Configuring the "Production Threshold" and "Minimum power-on time" parameters, the load control logic will activate the load only when the set power output is produced and, if the power level should drop, the load will still be kept in operation for the minimum duration selected.
Example of three-phase system (up to 100 kW overall) giving control over 4 single-phase loads on different phases.
Note.
Up to 16 loads or groups of loads can be controlled utilizing a similar number of relay actuators. Groups of controlled loads must be assigned a priority determining the order of disconnection.
Example of single-phase system (up to 33 kW overall) giving control over 4 loads and energy production using photovoltaic panels, with devices inserted in a dedicated control unit.
Notes
Up to 16 loads or groups of loads can be controlled utilizing a similar number of relay actuators. Groups of controlled loads must be assigned a priority determining the order of disconnection.
Setting the parameter "self-supply" for a given group, the load will activate when the power input to the grid exceeds the threshold and remains activated until production exceeds overall consumption. Configuring the "Production Threshold" and "Minimum power-on time" parameters, the load control logic will activate the load only when the set power output is produced and, if the power level should drop, the load will still be kept in operation for the minimum duration selected.
Example of system with display of single loads managed by 16A actuator.
Flush mounting actuator.
Bus 1/0
Actuator mounted on DIN rail. Actuator mounted on DIN rail, with optional diagnostics sensor monitoring residual current leakage to earth.
Bus 1/0 Bus 1/0
01456
Actuator mounted
on DIN rail
Washing machine
Note.
POWER draw can be measured on up to 20 single loads or groups of loads.
Example of system providing display of single loads and including energy meter.
Energy meter 01451 with 1 input. Energy meter 01450 with 3 inputs.
Bus 1/0
N
Note.
POWER draw can be measured on up to 20 single loads or groups of loads.
Example of system displaying non-electrical quantities (water, natural gas) by way of connection to pulse counter.
Bus 1/0 Bus 1/0
Example with second counter device.
Bus 1/0
Note.
POWER draw can be measured on up to 20 single loads or groups of loads.
Control device with four programmable buttons Home automation device with 4 programmable buttons allow- ing management of two functional units for single loads or sce- narios, to be completed with label and Eikon Tactil cover plate.
The device comprises two touch switches used typically to control relay actuators, dimmer actuators and rolling shutter actuators, over the Bus. These switches can be configured to operate with the sound system, for turning on and adjust- ing the volume, changing tracks and audio source, activating ambient listening and sleep functions; they can also be utilized individually for retrieving scenarios. The device is finished by fitting a glass cover plate; however, the switches will respond to mechanical pressure even without the plate in place, so that configuration and initial testing can be carried out while the device is still uncovered.
Conformity to Standards
EMC directive,
Standards EN 50428, EN 50491
Control device with six programmable buttons
Home automation device with 6 programmable buttons allow- ing management of three functional units for single loads or scenarios, to be completed with label and Eikon Tactil cover plate.
The device comprises three touch switches used typically to control relay actuators, dimmer actuators and rolling shutter actuators, over the Bus. These switches can be configured to operate with the sound system, for turning on and adjusting the volume, changing tracks and audio source, activating ambient listening and sleep functions; they can also be utilized individu- ally for retrieving scenarios.
The device is finished by fitting a glass cover plate; however, the switches will respond to mechanical pressure even without the plate in place, so that configuration and initial testing can be carried out while the device is still uncovered.
Conformity to Standards
EMC directive,
Standards EN 50428, EN 50491
Technical data
power supply on Bus 29 Vdc
current draw on Bus with all LEDs off 17 mA
current draw on Bus with all LEDs alight, colour white 35 mA
operating temperature - 5 °C to + 45 °C (indoor use)
Inputs
TP bus; Bus +, -
Technical data
power supply via Bus 29 Vdc
current draw on Bus with all LEDs off 17 mA
current draw on Bus with all LEDs alight, colour white 35 mA
operating temperature - 5 °C to + 45 °C (indoor use)
Inputs
TP bus; Bus +, -
Control device with four programmable buttons
21520 Glass touch control device, 4 independently programmable buttons to manage two functional units for single loads or scenarios, to be completed with label and glass touch cover plate - 2 modules
EIKON TACTIL
21520
Control device with six programmable buttons
21540 Glass touch control device, 6 independently programmable buttons to manage three functional units for single loads or scenarios, to be completed with label and glass touch cover plate - 3 modules
EIKON TACTIL
21540
Adhesive labels for customizing Eikon Tactil
21847 8 sheets of stickers with lightable symbols and lettering for standard functions for customizing Eikon Tactil controls
EIKON TACTIL
21847
Control device with two simple push buttons
Control device two simple push buttons, finished by fitting tabs. Used as a double or single button switch, depending on the interchangeable tab; these buttons can be operated only by pressing the bottom half of the tab.
Technical specifications
• possible configurations for each button:
- toggle on/off (sequential);
- ON only;
- OFF only;
- doorbell;
- activate scenario.
Conformity to Standards
EMC directive, Standard EN 50428
Control device with three simple push buttons
Used as three single button or one single and one double button switch, depending on the particular tabs fitted; these buttons can be operated only by pressing the bottom half of the tab.
Technical specifications
• tab: 1 double, 1 single or 3 single;
• functions available:
- toggle on/off (sequential);
- doorbell;
- ON only;
- OFF only;
- activate scenario.
Conformity to Standards
EMC directive, Standard EN 50428
Technical data
power supply on Bus 29 Vdc
current draw on Bus 10 mA
operating temperature - 5 °C to + 45 °C (indoor use)
Inputs
TP bus Bus +, -
Technical data
power supply via Bus 29 Vdc
current draw on Bus 16 mA
operating temperature - 5 °C to + 45 °C (indoor use)
Inputs
TP bus; Bus +, -
Control device with two simple push buttons
Two simple push buttons, to complete with 1- or 2-module buttons - 2 modules
EIKON
20520
grey
36
26,5
ARKÉ
19520
grey
36
26,5
IDEA
PLANA
16960
grey
16960.B
white
34,3
24,5
33,8
25,5
14520
white
20540
grey
ARKÉ
19540
grey
46,5
37
IDEA
PLANA
16980
grey
16980.B
white
44,95
36,5
44,3
36
14540
white
Control device with two rocker push buttons
Device with two rocker push buttons, finished by fitting tabs. Used as a double or single button switch, depending on the interchangeable tab; these buttons can be operated by press- ing both the top and the bottom half of the tab.
Technical specifications
Possible configurations for each button:
- ON/OFF switch;
- dimmer control;
- rolling shutters control;
- activation of two scenarios.
Conformity to Standards
EMC directive, Standard EN 50428
Control device with three rocker push buttons
Used as three single push button or one single and one double button switch, depending on the particular tabs fitted; these buttons can be operated by pressing both the top and the bottom half of the tab.
Technical specifications
• tab: 1 double and 1 single or 3 single;
• functions available:
- ON/OFF switch;
- dimmer control;
- rolling shutters control;
- activation of 2 scenarios.
Conformity to Standards
EMC directive, Standard EN 50428
Technical data
power supply on Bus 29 Vdc
current draw on Bus 10 mA
operating temperature - 5 °C to + 45 °C (indoor use)
Inputs
TP bus Bus +, -
Technical data
power supply on Bus 29 Vdc
current draw on Bus 16 mA
operating temperature - 5 °C to + 45 °C (indoor use)
Inputs
TP bus Bus +, -
Control device with two rocker push buttons
Two rocker push buttons, to complete with 1- or 2-module buttons - 2 modules
EIKON
ARKÉ
20521
grey
19521
grey
36
26,5
IDEA
PLANA
16961
grey
16961.B
white
14521
white
Control device with three rocker push buttons
Three rocker push buttons, to complete with 1- or 2-module buttons - 3 modules
EIKON
ARKÉ
IDEA
20541
grey
19541
grey
46,5
PLANA
16981
grey
16981.B
white
14541
white
Control device with two simple push buttons and actuator
Device comprising two simple push buttons and actuator with changeover relay output rated 8 A 120 - 230 V~, finished by fitting tabs. Used as a double or single button switch, depend- ing on the interchangeable tab; these buttons can be operated only by pressing the bottom half of the tab, and are configurable independently of the relay.
Technical specifications
• changeover relay output;
• loads controllable at 120-230 V~:
- resistive loads: 8 A (20,000 cycles)
- incandescent lamps: 8 A (20,000 cycles)
- fluorescent lamps and energy saving lamps: 1 A (20,000 cycles)
- electronic transformers: 4 A (20,000 cycles)
- ferromagnetic transformers: 8 A (20,000 cycles)
- cos ø 0.6 motors: 3.5 A (100,000 cycles)
- 12 – 24 Vdc loads: max 1 A;
• possible configurations for each button:
- toggle on/off (sequential);
- ON only;
- OFF only;
- doorbell;
- activate scenario.
Conformity to Standards
LV directive, EMC directive,
Standard EN 50428
Control device with three simple push buttons and actuator
Used as three simple button or one single and one double button switch, depending on the particular tabs fitted; these buttons are also configurable independently of the relay. The button can be operated only by pressing the bottom half of the tab.
Technical specifications
• changeover relay output;
• loads controllable at 120 - 230 V~:
- resistive loads: 8 A (20,000 cycles)
- incandescent lamps: 8 A (20,000 cycles)
- fluorescent lamps and energy saving lamps: 1 A (20,000 cycles)
- electronic transformers: 4 A (20,000 cycles)
- ferromagnetic transformers: 8 A (20,000 cycles)
- cos ø 0.6 motors: 3.5 A (100,000 cycles);
- 12 – 24 Vdc loads: max 1 A;
• tab: 1 double and 1 single or 3 single;
• functions available:
- toggle on/off (sequential);
- doorbell;
- ON only;
- OFF only;
- activate scenario.
Conformity to Standards LV Directive, EMC Directive, Standard EN 50428
Technical data
power supply on Bus 29 Vdc
current draw on Bus 10 mA
operating temperature - 5 °C to + 45 °C (indoor use)
Inputs Outputs
Technical data
power supply on Bus 29 Vdc
current draw on Bus 16 mA
operating temperature - 5 °C to + 45 °C (indoor use)
Inputs Outputs
Control device with two simple push buttons and actuator
Two simple push buttons and actuator with 8 A 120-230 V~ change-over relay output, to complete with 1- or 2-module buttons - 2 modules
EIKON
20525
grey
46,5
37
ARKÉ
19525
grey
IDEA
PLANA
16965
grey
16965.B
white
44,8
36,5
44,3
36
14525
white
Control device with three simple push buttons and actuator
Three simple push buttons and actuator with 8 A 120-230 V~ change-over relay output, to complete with 1- or 2-module buttons - 3 modules
EIKON
46,5
37
20545
grey
ARKÉ
19545
grey
IDEA
PLANA
16985
grey
16985.B
white
44,95
36,5
44,3
36
14545
white
Control device with two rocker push buttons and actuator
Device comprising two rocker push buttons and actuator with changeover relay output rated 8 A 120 - 230 V~, finished by fitting interchangeable tabs.
These buttons can be operated by pressing both the top and the bottom half of the tab, and are also configurable indepen- dently of the relay. The relay can be configured to operate both in monostable and in bistable mode.
Technical specifications
• changeover relay output;
• loads controllable at 120-230 V~:
- resistive loads: 8 A (20,000 cycles)
- incandescent lamps: 8 A (20,000 cycles)
- fluorescent lamps and energy saving lamps: 1 A (20,000 cycles)
- electronic transformers: 4 A (20,000 cycles)
- ferromagnetic transformers: 8 A (20,000 cycles)
- cos ø 0.6 motors: 3.5 A (100,000 cycles)
- 12 – 24 Vdc loads: max 1 A;
• possible configurations for each button:
- ON/OFF switch;
- dimmer control;
- rolling shutters control;
- activation of two scenarios.
Conformity to Standards LV Directive, EMC Directive, Standard EN 50428
Technical data
power supply on Bus 29 Vdc
current draw on Bus 10 mA
operating temperature - 5 °C to + 45 °C (indoor use)
Inputs Outputs
Control device with three rocker push buttons and actuator
Used as three single push button or one single and one double button switch, depending on the particular tabs fitted; these buttons are also configurable independently of the relay.
The button can be operated by pressing both the top and the bottom half of the tab. The relay can be configured to operate both in monostable and in bistable mode.
Technical specifications
• changeover relay output;
• loads controllable at 120 - 230 V~:
- resistive loads: 8 A (20,000 cycles)
- incandescent lamps: 8 A (20,000 cycles)
- fluorescent lamps and energy saving lamps: 1 A (20,000 cycles)
- electronic transformers: 4 A (20,000 cycles)
- ferromagnetic transformers: 8 A (20,000 cycles)
- cos ø 0.6 motors: 3.5 A (100,000 cycles)
- 12 – 24 Vdc loads: max 1 A;
• tab: 1 double, 1 single or 3 single;
• functions available:
- ON/OFF switch;
- rolling shutters control;
- dimmer control;
- activation of 2 scenarios.
Conformity to Standards LV Directive, EMC Directive, Standard EN 50428
Technical data
power supply on Bus 29 Vdc
current draw on Bus 16 mA
operating temperature - 5 °C to + 45 °C (indoor use)
Inputs
TP bus Bus +, -
Outputs
relay contacts NO, C, NC
Control device with two push rocker buttons and actuator
Two rocker push buttons and actuator with 8 A 120-230 V~ change-over relay output, to complete with 1- or 2-module buttons - 2 modules
EIKON
20526
grey
46,5
37
ARKÉ
19526
grey
46,5
37
IDEA
PLANA
16966
grey
16966.B
white
44,8
36,5
44,3
36
14526
white
Control device with three rocker push buttons and actuator
Three rocker push buttons and actuator with 8 A 120-230 V~ change-over relay output, to complete with 1- or 2-module buttons - 3 modules
EIKON
20546
grey
46,5
37
ARKÉ
19546
grey
46,5
37
IDEA
PLANA
16986
grey
16986.B
white
44,8
36,5
44,3
36
14546
white
Control device with two rocker push buttons and actuator for shutters
Device comprising two rocker push buttons and actuator for rolling shutters, with 1 channel and 4 A relay output, finished by fitting interchangeable tabs. These buttons can be operated by pressing both the top and the bottom half of the tab, and are also configurable independently of the shutters actuator.
Technical specifications
• relay output;
• loads controllable at 120-230 V~:
- resistive loads: 4 A (20,000 cycles)
- cos ø 0.6 motors: 2 A (20,000 cycles)
• possible configurations for each button:
- ON/OFF switch;
- rolling shutters control;
- dimmer control;
- activation of 2 scenarios.
Conformity to Standards LV Directive, EMC Directive, Standard EN 50428
Control device with two rocker push buttons and actuator for louvre shutters
Device for controlling conventional rolling shutters and those with louvres (Venetian style), used as double or single button depending on the tab.
The buttons are configurable independently of the actuator and can be operated by pressing both the top half and the bottom half of the tab.
Technical specifications
• relay output;
• loads controllable at 120-230 V~:
- resistive loads: 4 A (20,000 cycles);
- cos ø 0.6 motors: 2 A (20,000 cycles)
• tab: double or single;
• functions available:
- ON/OFF switch;
- control of rolling shutters;
- dimmer control;
- activation of 2 scenarios.
Conformity to Standards LV Directive, EMC Directive, Standard EN 50428
Technical data
power supply on Bus 29 Vdc
current draw on Bus 22 mA
operating temperature - 5 °C to + 45 °C (indoor use)
Inputs Outputs
Technical data
power supply on Bus 29 Vdc
current draw on Bus 22 mA
operating temperature - 5 °C to + 45 °C (indoor use)
Inputs Outputs
Control device with two rocker push buttons and actuator for shutters
Two rocker push buttons and roller blind actuator, relay output for cosø 0.6 2 A 120-230 V~ motor, to complete with interchangeable 1- or 2-module buttons - 2 modules
EIKON
46,5
37
20527
grey
IDEA
PLANA
16967
grey
16967.B
white
44,8
35
43,3
36
14527
white
Control device with two rocker push buttons and actuator for louvre shutters
Two rocker push buttons and actuator for 1 roller blind laths positioning, relay output for cosø 0.6 2 A 120-230 V~ motor, to complete with interchangeable 1- or 2-module buttons - 2 modules
EIKON
20527.1
grey
46,4
38
ARKÉ 46,5
37
19527.1
grey
IDEA
44,7
36,5
16967.1
grey
16967.1.B
white
PLANA
14527.1
white
44,2
37
Control device with three rocker push buttons and actuator for shutters
Used as three single button or one single and one double button switch, depending on the particular tabs fitted; these buttons are also configurable independently of the actuator.
The buttons can be operated by pressing both the top half and the bottom half of the tab.
Main characteristics
• relay output;
• loads controllable at 120-230 V~:
- resistive loads: 8 A (20,000 cycles)
- cos ø 0.6 motors: 3.5 A (100,000 cycles)
• tab: 1 double, 1 single or 3 single;
• functions available:
- ON/OFF switch;
- rolling shutters control;
- dimmer control;
- activation of 2 scenarios.
Conformity to Standards LV Directive, EMC Directive, Standard EN 50428
Technical data
power supply on Bus 29 Vdc
current draw on Bus 25 mA
operating temperature - 5 °C to + 45 °C (indoor use)
Inputs Outputs
Control device with three rocker push buttons and actuator for shutters
Three rocker push buttons and roller blind actuator, relay output for cosø 0.6 2 A 120-230 V~ motor, to complete with 1- or 2-module buttons
- 3 modules
EIKON
20547
grey
46,5
37
ARKÉ
IDEA
PLANA
16987
grey
19547
grey
16987.B
white
14547
white
Control device with two rocker push buttons and actuator for universal SLAVE dimmers, 230 V~ 50 Hz Device for controlling universal SLAVE dimmers 230 V~ 50 Hz, adjustable electronic power supplies for LEDs and lamps.
The device cannot control the load directly. Used as a double or single button, depending on the particular tabs fitted. The buttons are configurable independently of the SLAVE dimmer control circuit and can be operated by pressing both the top half and the bottom half of the tab.
Important.
Lamps or electronic power supply units controllable from a sin- gle device must belong to the same type. It is not possible to control simultaneously with the same device the white LEDs and the RGB LEDs.
Technical specifications
• finished by fitting tabs: 1 double or 2 single;
• button functions available:
- ON/OFF switch;
- rolling shutters control;
- dimmer control;
- activation of 2 scenarios;
• dimmer functions available:
- on/off/dim;
- change absolute colour;
- hue/saturation/brightness adjustment;
- FADING-SHOW;
- parameters:
a. "Flash Start" mode for CFL lamps;
b. "Ramp";
c. switch-off delay and "warning" function;
d. phase cut: LE/TE;
• compatible with updatable By-me control units (21509, 01960);
• not compatible with 2-module flush mounting By-me control units (20510, 16950, 14510);
• the RGB feature is not supported for art.16969.
Note.
Maximum length of cables connecting dimmer actuator and uni- versal SLAVE dimmer: 100 m.
MASTER and SLAVE dimmers must be configured in the same operating mode.
Conformity to Standards
LV directive, EMC Directive, Standard EN 50428, EN 50491
Technical data
mains power supply 230 V~, 50 Hz
power supply on Bus 29 Vdc
current draw on Bus 13 mA
operating temperature - 5 °C to + 45 °C (indoor use)
Inputs
TP bus Bus +, -
power supply L1, L2
Outputs
20529 - Connections with universal SLAVE dimmers (20137, 14137, 19137, 16604, 01871)
L N
20416
20416
19416 19416
16460 16460
14416 14416
20529-19529 20137-19137 20137-19137
16969-14529 16604-14137 16604-14137
L1 S L2
Controllable loads
Controllable loads 20529, 19529, 14529 16969
SLAVE dimmers
(20137, 19137, 16604, 14137, 01871) maximum 3 maximum 3
LED lamps (02662) or RGB lamps (02663) maximum 10 Not applicable
Adjustable electronic power supplies for LED (01874, 01875) maximum 10 maximum 10
RGB electronic power supplies (01876) maximum 10 Not applicable
Control device with two rocker push buttons and actuator for universal SLAVE dimmers, 230 V~ 50 Hz
Two rocker push buttons and actuator for SLAVE dimmer 230 V~ 50 Hz for: LED lamps and electronic transformers, RGB lamps and electronic transformers, to complete with interchangeable 1- or 2-module buttons - 2 modules
EIKON
grey
ARKÉ
IDEA
PLANA
16969
grey
19529
grey
16969.B
white
14529
white
Control device with three rocker push buttons and universal MASTER dimmer actuator, 230 V~ 50 Hz Device with three rocker push buttons and MASTER dimmer actua- tor operating off 230 V~ 50 Hz, for incandescent lamps rated 40- 300 W, electronic transformers rated 40-200 VA, CFL lamps rated 10-120 W, LED lamps rated 3-120 W, incorporating fuse. Abso- lutely no buzz. Device directs a synchronization signal to SLAVE dimmers (maximum 3) and can control the load directly. Used as three single button or one single and one double button switch, de- pending on the particular tabs fitted. The buttons are also configur- able independently of the pilot SLAVE dimmer pilot section. Buttons can be operated by pressing both the top half and the bottom half of the tab.
Important. Lamps controllable from a single MASTER or SLAVEd- immer must all be identical. All controlled loads must be declared dimmable by the manufacturer. Check the dimmer compatibility indicated on the lamp packaging: LE (Leading Edge) or TE (Trailing Edge). If there is no indication, the lamp can operate in either mode (selected at the discretion of the installer).
Technical specifications
• finished by fitting tabs: 1 double and 1 single, or 3 single;
• F2.5 AH 250 V high breaking capacity fuse incorporated;
• button functions available:
- ON/OFF switch;
- control of rolling shutters;
- dimmer control;
- activation of 2 scenarios;
• dimmer functions available:
- on/off/dim;
- change absolute brightness;
- actuate/save scenarios;
- parameters:
a. dimming rate;
b. phase cut: LE/TE;
c. "Flash Start" mode for CFL lamps;
d. "Ramp";
e. switch-off delay and "warning" function;
f. timer controlled change of absolute brightness;
• protection against short-circuits at power-up;
• thermal protection;
• MASTER function: to avoid exceeding the maximum power that can be controlled by each dimmer, up to 3 universal SLAVE dim- mers (01871, 20137, 14137, 19137, 16604) can be associated with a single MASTER device for a maximum load of 1800 W (VA), corresponding to 500 W/VA max connected to each of the 3 SLAVE dimmers and 300 W to the master dimmer;
• not suitable for controlling motors (e.g. ceiling fans, extractor fans);
• compatible with updatable By-me control units (21509, 01960);
• not compatible with 2-module flush mounting By-me control units (20510, 16950, 14510).
Note. Maximum length of cables connecting universal MASTER dimmer and universal SLAVE dimmer: 100 m. Connect at least the minimum load required to the universal MASTER dimmer. MASTER and SLAVE dimmers must be configured in the same operating mode.
Conformity to Standards LV Directive, EMC Directive, Standards EN 50428, EN 50491
Technical data
mains power supply 230 V~
power supply on Bus 29 Vdc
current draw on Bus 16 mA
operating temperature - 5 °C to + 45 °C (indoor use)
Inputs
TP bus Bus +, -
power supply L, N
load Outputs
synchronization S
Control device with three rocker push buttons and universal MASTER dimmer actuator, 230 V~ 50 Hz
Three rocker push buttons and actuator for MASTER dimmer 230 V~ 50 Hz for: 40-300 W incandescent lamps, 40-200 VA electronic transfomers, 10-120 W CFL lamps, 3-120 W LED lamps and LED electronic transfomers, protection fuse, to complete with interchangeable 1- or 2-module buttons
- 3 modules
EIKON
20549
grey
ARKÉ
19549
grey
grey white
14549
white
Eikon Tactil control devices
2- and 3-module control devices
1-module set of 2 tabs
2- module control device with button
1-module set of 3 tabs
3- module control device with button
1- and 2-module tabs
Eikon
For items in white version: add .B to the code indicated for the grey version of the item. For items in Next version: add .N to the code indicated for the grey version of the item.
2-module push button 3-module push button 1-module interchangeable buttons 2-module interchangeable buttons
Simple push button
Neutral
20531
Customizable*
20531.0
With name tag
20531.1T
Neutral
20532
Customizable*
20532.0
With name tag
20532.1T
Plain Plain
20520 20540
Plain with actuator Plain with actuator
20525 20545
Rocker push button
Neutral
20531.S
With two name tags
20531.2T
With symbols ON/OFF 20531.20
With universal control symbols 20531.25
With directional arrows 20531.21
Customizable*
20531.S0
Neutral
20532.S
With directional arrows 20532.21
Customizable*
20532.S0
With symbols ON/OFF 20532.20
With universal control symbols 20532.25
Rocker Rocker
20521 20541
Rocker with actuator Rocker with actuator
20526 20546
Rocker push button with actuator
Rocker for rolling shutter Rocker for rolling shutter
20527
20527.1 20547
Rocker for SLAVE dimmers
20529 Rocker for MASTER dimmers
20549
Arké For items in white version: add .B to the code indicated for the grey version of the item.
2-module push button 3-module push button 1-module interchangeable buttons 2-module interchangeable buttons
Simple push button
Neutral
19531
Customizable*
19531.0
Neutral
19532
Customizable*
19532.0
Plain Plain
19520 19540
Plain with actuator Plain with actuator
19525 19545
Rocker push button
Neutral
19531.S
With universal control symbols 19531.25
With symbols ON/OFF 19531.20
Customizable*
19531.S0
With directional arrows 19531.21
Neutral
19532.S
With universal control symbols 19532.25
With symbols ON/OFF 19532.20
With directional arrows 19532.21
Rocker Rocker
19521 19541
Rocker with actuator Rocker with actuator
19526 19546
Rocker push button with actuator
Rocker for rolling shutter Rocker for rolling shutter
19527.1 19547
Rocker for SLAVE Rocker for MASTER
dimmers dimmers
19529 19549
Idea
For items in white version: add .B to the code indicated for the grey version of the item.
2-module push button 3-module push button 1-module interchangeable buttons 2-module interchangeable buttons
Simple push button
Neutral
16971
With generic symbol 16971.10
With name tag
16971.1T
Neutral
16972
With generic symbol 16972.10
With name tag
16972.1T
Plain Plain
16960 16980
Plain with actuator Plain with actuator
16965 16985
Rocker push button
Neutral
16971
With symbols ON/OFF 16971.20
With universal control symbols 16971.25
With directional arrows 16971.21
With name tags
16971.2T
Neutral
16972
With symbols ON/OFF 16972.20
With universal control symbols 16972.25
With directional arrows 16972.21
Rocker Rocker
16961 16981
Rocker with actuator Rocker with actuator
16966 16986
Rocker push button with actuator
Rocker for rolling shutter Rocker for rolling shutter
16967 16987
Rocker for SLAVE Rocker for MASTER
dimmers dimmers
16969 16989
Plana
For items in Silver version: add .SL to the code indicated for the grey version of the item.
2-module push button 3-module push button 1-module interchangeable buttons 2-module interchangeable buttons
Simple push button
Neutral
14531
With generic symbol 14531.10
With name tag
14531.1T
Neutral
14532
With generic symbol 14532.10
With name tag
14532.1T
Plain Plain
14520 14540
Plain with actuator Plain with actuator
14525 14545
Rocker push button
Neutral
14531.S
With symbols ON/OFF 14531.20
With universal control symbols 14531.25
With directional arrows 14531.21
With name tags
14531.2T
Neutral
14532.S
With symbols ON/OFF 14532.20
With universal control symbols 14532.25
With directional arrows 14532.21
Rocker Rocker
14521 14541
Rocker with actuator Rocker with actuator
14526 14546
Rocker push button with actuator
Rocker for rolling shutter Rocker for rolling shutter
14527 14547
Rocker for SLAVE Rocker for MASTER
dimmers dimmers
14529 14549
*Customizations: see libraries with reference symbols in the Eikon, Arké, Idea and Plana catalogues.
Eikon: 1-module button
20531 .B .N Without symbol, for simple push button
20531.0 .B .N Without symbol, for simple push button, customizable on request
20531.S .B .N Without symbol, for rocker push button
20531.S0 .B .N Without symbol, for rocker push button, customizable on request
20531.20 .B .N With ON and OFF symbols, for rocker push button
EIKON
grey
white
Next
grey
20531.0.B
white
20531.0.N
Next
grey
20531.S.B
white
20531.S.N
Next
grey
20531.S0.B
white
20531.S0.N
Next
grey
20531.20.B
white
20531.20.N
Next
Arké: 1-module button
19531 .B Without symbol, for simple push button
19531.0 .B Without symbol, for simple push button, customizable on request
19531.S .B Without symbol, for rocker push button
19531.S0 .B Without symbol, for rocker push button, customizable on request
ARKÉ
19531
grey
19531.S
grey
19531.B
white
19531.S.B
white
19531.0
grey
19531.S0
grey
19531.0.B
white
19531.S0.B
white
Eikon: 1-module button
20531.21 .B .N With regulation symbols, for rocker push button
20531.25 .B .N With universal regulation symbols, for rocker push button
20531.1T .B .N With name-plate, for simple push button
20531.2T .B .N With 2 name-plates, for rocker push button
EIKON
20531.21
grey
20531.1T
grey
20531.21.B
white
20531.1T.B
white
Next
20531.1T.N
Next
grey
20531.2T
grey
white
20531.2T.B
white
Next
20531.2T.N
Next
Arké: 1-module button
19531.20 .B With ON and OFF symbols, for rocker push button
19531.21 .B With directional arrows symbols, for rocker push button
19531.25 .B With universal regulation symbols, for rocker push button
ARKÉ
19531.20
grey
19531.20.B
white
19531.21
grey
19531.25
grey
19531.21.B
white
19531.25.B
white
Idea: 1-module button
16971 .B Without symbol, for simple push button
16971.10 .B With general symbol, for simple push button
16971.20 .B With ON and OFF symbols, for rocker push button
16971.21 .B With directional arrows symbols, for rocker push button
IDEA
grey
white
grey
white
grey
white
grey
white
Plana: 1-module button
14531 .SL Without symbol, for simple push button 14531.S .SL Without symbol, for rocker push button 14531.10 .SL With general symbol, for simple push button
14531.20 .SL With ON and OFF symbols, for rocker push button
14531.21 .SL With directional arrows symbols, for rocker push button
PLANA
white
Silver
white
Silver
white
Silver
white
Silver
white
Silver
Idea: 1-module button
16971.25 .B With universal regulation symbols, for rocker push button
16971.1T .B With name-plate, for simple push button
16971.2T .B With 2 name-plates, for rocker push button
IDEA
16971.25
grey
white
grey
white
grey white
Plana: 1-module button
14531.25 .SL With universal regulation symbols, for rocker push button
14531.1T .SL With name-plate, for simple push button
14531.2T .SL With 2 name-plates, for rocker push button
PLANA
14531.25
white
14531.25.SL
Silver
white
Silver
white Silver
Eikon: 2-module button
20532 .B .N Without symbol, for simple push button
20532.0 .B .N Without symbol, for simple push button, customizable on request
20532.S .B .N Without symbol, for rocker push button
20532.S0 .B .N Without symbol, for rocker push button, customizable on request
EIKON
20532
grey
20532.B
white
20532.N
Next
grey
white
Next
grey
white
Next
grey
white
Next
Arké: 2-module button
19532 .B Without symbol, for simple push button
19532.0 .B Without symbol, for simple push button, customizable on request
19532.S .B Without symbol, for rocker push button
ARKÉ
19532
grey
19532.B
white
19532.0
grey
19532.S
grey
19532.0.B
white
19532.S.B
white
Eikon: 2-module button
20532.20 .B .N With ON and OFF symbols, for rocker push button
20532.21 .B .N With arrows symbol, for rocker push button
20532.25 .B .N With universal regulation symbols, for rocker push button
20532.1T .B .N With name-plate, for simple push button
EIKON
grey
white
Next
grey
white
Next
20532.25
grey
20532.25.B
white
20532.25.N
Next
20532.1T
grey
20532.1T.B
white
20532.1T.N
Next
Arké: 2-module button
19532.20 .B With ON and OFF symbols, for rocker push button
19532.21 .B With arrows symbol, for rocker push button
19532.25 .B With universal regulation symbols, for rocker push button
ARKÉ
19532.20
grey
19532.20.B
white
19532.21
grey
19532.25
grey
19532.21.B
white
19532.25.B
white
Idea: 2-module button
16972 .B Without symbol, for simple and rocker push button 16972.10 .B With general symbol, for simple push button 16972.20 .B With ON and OFF symbols, for rocker push button
IDEA
grey
white
grey
white
grey white
Plana: 2-module button
14532 .SL Without symbol, for simple push button 14532.S .SL Without symbol, for rocker push button 14532.10 .SL With general symbol, for simple push button
14532.20 .SL With ON and OFF symbols, for rocker push button
PLANA
white
Silver
white
Silver
white
Silver
white
Silver
Idea: 2-module button
16972.21 .B With arrows symbol, for rocker push button
16972.25 .B With universal regulation symbols, for rocker push button
16972.1T .B With name-plate, for simple push button
IDEA
grey
white
16972.25
grey
white
grey white
Plana: 2-module button
14532.21 .SL With arrows symbol, for rocker push button
14532.25 .SL With universal regulation symbols, for rocker push button
14532.1T .SL With name-plate, for simple push button
PLANA
white
Silver
14532.25
white
14532.25.SL
Silver
white Silver
Receiver for infrared remote control
This device receives signals from the remote control 01849 and has 4 channels in reception. In addition to performing the functions of an On/Off switch, it can be used to operate rolling shutters, control dimmers, toggle status (sequential control), and activate scenarios.
Technical specifications
• input: IR protocol RC5;
• reception channels: 4;
• functions available:
- ON/OFF switch;
- dimmer control;
- rolling shutters control;
- toggle on/off (sequential);
- activation of scenarios.
Conformity to Standards
EMC directive, Standards EN 50428
01849 - Infrared remote control
Device with 14 channels for infrared receivers.
Technical specifications
• power supply: 2 x 1.5 V alkaline battery, type AAA LR03
• maximum range: 5 m;
• output: IR protocol RC5.
Technical data
power supply on Bus 29 Vdc
current draw on Bus 10 mA
operating temperature - 5 °C to + 45 °C (indoor use)
Inputs
TP bus Bus +, -
Directionally adjustable passive infrared presence detector
The PIR presence detector is a device able to generate an alarm message on detecting any motion of heat-emitting bodies within its area of coverage. The detector is equipped with a swivel lens to allow installation near ceiling height, and with eyelids for adjustment of the coverage area.
Technical specifications
• maximum range: 10 m;
• pan adjustment: 40°;
• tilt adjustment: 22°;
• configuration button;
• indicator LED;
• facility of configuration from automation menu.
Conformity to Standards
EMC directive, Standard EN 50428
Technical data
power supply on Bus 29 Vdc
current draw on Bus 10 mA
operating temperature - 5 °C to + 45 °C (indoor use)
Inputs
TP bus Bus +, -
Receiver for infrared remote control
IR remote control receiver - 2 modules
EIKON
20516
grey
ARKÉ
20516.B
white
20516.N
Next
IDEA
PLANA
Infrared remote control
01849 14-channel infrared remote control
19516
grey
16956
grey
14516
white
19516.B
white
16956.B
white
14516.SL
Silver
36,5
|
